Thermal Image Sensor Camera Module with MLX90640 IR Sensor Compatible for M5StickC IoT Development Board Finger Computer M5Stack® for Arduino - products that work with official Arduino boards

Description: THERMAL HAT is an M5StickC compatible thermal camera. Same as M5Unit THERMAL, this stickc HAT module Integrates MLX90640 which can be used to measure the surface temperature of an object and form a thermographic image by a temperature gradient composed of different surface temperatures. Now that it has a cover of a case of stickc HAT, you can pretty much move all the implementations to stickc-based controller, featured with tiny, low-cost and highly-productization. The MLX90640 Infrared (IR) sensor array combines high resolution and reliable operation in harsh environments, providing a cost-effective alternative to more expensive high-end thermal imaging cameras. Unlike the case of a microbolometer, the sensor does not require frequent recalibration, ensuring continuous monitoring and reducing system cost. The field of view (FoV) option includes a standard 55 x 35 version and a wide angle version of 110 x 75. This Unit is 11075 FoV, also known as the BAA package. Connect with M5StickC via GOIO 0/26 (I2C add: 0x33). Product Features: M5StickC Compatible Operating Voltage: 3V ~ 3.6V Current Consumption: 23mA Field of View: 55x35 Measurement Range: -40C ~ 300C Resolution: 1.5C Refresh Rate: 0.5Hz-64Hz Operating temperature: -40C ~ 85C Package Included: 1x THERMAL CAMERA HAT Applications: High precision non-contact temperature measurements Intrusion / Movement detection Visual IR thermometers Schematic: Links: Official Channel Official forum MLX90640 Datasheet EasyLoader click to download EasyLoader 1.EasyLoader is a simple and fast program burner, and each product page has a product-related case program for EasyLoader. 2.After downloading the software, double-click to run the application, connect the M5 device to the computer via the data cable, select the port parameters, and click "Burn" to start burning. Example: for Pin Map: M5StickC GPIO0 GPIO26 5V GND HAT THERMAL SDA SCL 5V GND
