Terminal Serie DT hembra 16-20 Awg

Código ErreBi: 29162 Código productor: 0462-201-16141 Productor: Deutsch Embalaje: 3 piezas Nota: Cantidad 1 corresponde a 3 piezas Product Type Features Sealed: Yes Primary Locking Feature: None Wire Type: Copper Body Features Seal Type: Family Seal Contact Features Terminal Style: Socket Mating Pin Diameter: (Size 16) 1.6 mm [ (Size 16) .063 in ] Interface Plating: Nickel (Ni) Typical Current Rating (A): 13 Termination Features Termination Method: Crimp Crimp Type: Radial Dimensions Wire Size Search (mm²): .5, .75, 1, 1.5 Wire Size Search (AWG): 16, 18, 20 Wire Size: .5 – 1.5 mm² [ 20 – 16 AWG ] Usage Conditions Operating Temperature (Max) (°C): 80, 85, 90, 100, 105, 110, 120, 125 Operating Temperature (Max) (°F): 176, 185, 194, 212, 221, 230, 248, 257 Operating Temperature Range: -55 – 125 °C [ -67 – 257 °F ] Other Terminal Transmits: 0 – 24 A (Low Power) Scheda Tecnica Serie: DT Amperaje: 13A Temperatura de funcionamiento: -55°C a +125°C Material de contacto: Cobre Montaje: En
