Te/connectivity - Conector Assy Hembra 10 vìas

Código ErreBi: 30311 Código productor: 493577-2 Productor: TE/Connectivity Product Type Features -Connector Style: Housing for female terminals -Connector System: Wire-to-Board, Wire-to-Device -Sealable: Yes -Hybrid Connector: No -Primary Locking Feature: On the Terminal -Strain Relief: No -Row-to-Row Spacing: 6mm[.236in] Configuration Features -Number of Positions: 10 -Number of Rows: 2 Electrical Characteristics -Nominal Voltage Architecture(V): 12 -Operating Voltage(VDC): 12 Body Features -Color: Black -Cable Exit Angle: 180° -Body Material: PBT Contact Features -Mating Tab Width: 2.8mm[.11in] Mechanical Attachment -Mounting Feature: Without -Terminal Position Assurance: Yes -Polarized: Yes Housing Features -Centerline (Pitch): 6mm[.236in] Dimensions -Width: 33mm[1.299in] -Height: 28.7mm[1.13in] -Length: 47.1mm[.185in] Usage Conditions -Operating Temperature Range: -40 – 130°C[-40 – 266°F] Operation/Application -Circuit Application: Signal Industry Standards -UL Flammability
