TWO TREES® KFB3.0 Controller Mainboard Compatible Ramps1.4/Mega2560 R3 Support A4988/DRV8825/TMC2100 Reprap 3D Printer

Parameters Size 100 100mm Screw hole size 3 3mm 4 Power input 12V 24V We recommend using 12V Support motor driven quantity 5Motor drive type A4988 DRV8825 LV8729 MS4998 MS4989 TMC2100 TMC2208 TMC2130 etc Support control panel LCD2004 LCD12864 LCD1602 touch color screen Compile environment IDEFirmware Marlin Features The power depressurized stabilizer chip USES the L5970D chip a loss of up to 1A the input voltage is 4 4V to 36V The processor USES the tamega2560 chip and the 54 output meets the output interface The hot bed MOS tube adopts F8736 chip the largest 18A current no heating and ulfimaker the same solution using the Wj500V type wiring terminal which is larger easier to connect and durable Tantalum capacitance filter to collect temperature anti interference more precision Notice 1 Dont connect the waire of the mother board or change various modules interface when electrified 2 Pay attention to the Positive and negative of the wire 3 Please check to determine whether the connection interface is correct so as not to damage the motherboard before open telegram 4 when in emergency occurs please press the RESET button on the motherboard or disconnectPackage Included 1 xKFB3 0 Controller Mainboard
