TWO TREES® 5 Pcs TMC2209 V1.0 Stepper Motor Driver in-line Stepper Motor Driver Board Ultra Quiet Larger Driver Current

Features Excellent Mute Effect Can 16 Microstep to 256 subdivisions Larger Driver Current maximum current up to 2 5A and stable printing current up to 1 8A Compared with Other TMC Drivers heat Efficiencyis lower and better heat dissipation Support UART Perfectly fits MKS SGEN LDIR STEP mode Under Normal Mode directly adjust the microsteps by jumper caps and adjust driver current by knob on the PCBCalculation formula I VrefMaximum Current is up to 2 5A Stable current recommended to lower than 1 8AUART mode Hardware is connected to SGEN L directly configure hardwares by jumper caps which doesnt need jumper required The UART pin on the driver and it site pin has been connected by a resistor R8 You can insert MKS TMC2209 onto MKS SGEN L directlyUsing other brands of motherboards requires hardware modification according to the motherboard itselfIn the UART mode insert the jumper caps onto the UART pin areas and pull out all other jumper caps for normal operationPackage Included 5 TMC2209 Drivers
