TTL level NEO-6M GPS Module with Cirocomm Antenna with Eeprom NMEA 2.3 Protocol

Features: Parameter Specification Electrical Characteristics Chipset NEO-6M Receiving Format GPS,QZSS and SBAS Frequency GPS L1,SBAS L1 Channels 50 Searching Channel Sensitivity Tracking -162dBm Reacquisition -156dBm Cold start -147dBm Accuracy Position Horizontal 2.0 m CEP 2D RMS SBAS Enable (Typical Open Sky) Velocity 0.1m/sec 95% (SA off) Timing 1us synchronized to GPS time Acquisition Time Cold Start 29s Warm Start 25s Hot Start 1s Data and Update Rate Support Rate 4800bps to 921600bps,Default 9600bps Data Level Default RS-232 level Data Protocol Default NMEA-0183 Concurrent GNSS 1Hz-10Hz,Default 1Hz Operational Limits Altitude 50,000m Max Velocity 515m/s Max Acceleration Less than 4g Power consumption VCC DC Voltage 3.6V-5.5V,Typical: 5.0V Current Capture 50mA/5.0V Mechanical Specifications Dimension 28mm*28mm*6mm Weight 7.6g Connector 1.25mm spacing between the 6pins patch seat Environment Operating temp -40 C ~ +85C Storage Temp -40C ~ +105C LED built-in LED TX LED:blue.The data output, TX LED flashing PPS LED:red.PPS LED not bright when GPS not fixed,flashing when fixed Pcakage Included: 1 x NEO-6M(232) GPS Module 1 x 15cm Cable
