TRM01 DC 5V/12V/24V Delay Timer Relay Multi-functional Delay Time Relay Self-locking Relay Delay Trigger Delay Relay

TRM01 DC 5V/12V/24V Delay Timer Relay Multi-functional Delay Time Relay Self-locking Relay Delay Trigger Delay Relay
sku: 1835824
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$12.99
Shipping from: China
   Description
Description TRM01 time delay relay module adopts high quality components and is carefully designed and processed It has stable performance and simple operation and can be widely used in various control occasions requiring time delay self locking The module has 4 preset functions which can meet various application requirements and can be customized and added other specific functions according to user needs Features 1 With delayed pull in delayed disconnection self locking and triggered delay functions 2 With anti reverse power supply function the module will not be damaged if it is reversed 3 There are three working voltage versions of 5V 12V 24V for users to choose 4 Timing duration can be arbitrarily set between 0 1 second and 120 seconds 5 The parameters can be saved and the setting contents will not be lost after power off 1 Module functionThe user can select one of the following 4 functions by pressing the button The delay time can be selected by adjusting the potentiometer The delay time T1 can be adjusted between 0 1 second and 120 seconds Function F1 After the delay of T1 time from power on the relay pulls in then sends a high level pulse signal to the X1 interface at any time This function resets and restarts operation Function F2 Power on delay disconnection The relay pulls in when the power is turned on After the pull in time of T1 the relay opens and a high level pulse signal is given to the X1 interface at any time This function resets
