TOPPING D10S MINI Digital USB DAC XMOS XU208 ES9038Q2M PCM384KHz DSD256 HIFI Audio Decoder

Specifications Size 10 3cmx 14 6cm x 3 7cmWeight 323gPower input DC5V 0 5A USB power supply Colour Black SilverInput USBOutput COAX OPT RCADisplay Customized digital tubeUSB IN 44 1kHz 384kHz 16Bit 32BitDSD64 DSD256 Native DSD128 Dop OPT COAX Out 44 1kHz 192kHz 16Bit 24BitDSD64 Dop D10s decoding specification LineOut USB In 96kHz THD N 1kHz A wt 0 0002 SNR 1kHz A wt 120dBDynamic Range 1kHz A wt 120dBFrequency Response 20Hz 20kHz 0 1dB 20Hz 40kHz 0 4dB Output Level 2Vrms 0dBFSNoise A wt 2 5uVrmsChannel Crosstalk 1kHz 135dBChannel Balance 0 02dBOutput Impedance 20ΩFeatures D10s is compatible with 16 32bit 44 1 384kHz and DSD64 DSD256D10s uses XMOS XU208 for USB interface and uses customized driver which from Thesycon for better compatibility with high resolution audio file especially DSD nativeEven some USB port support power after the PC has shut down D10s still will synchronously power on off with the PCD10s can accurately indicate the audio format PCM or DSD and a sampling rate of the playing musicOrange LED is soft and not dazzling even at nightD10s has an OP amp socket DIYer could change the OP amp to get a different soundConnect to active speakers Connect D10s to your active speakers D10s provides not only DSD and higher specification PCM compatibility but also a better sound quality than your computer s built in sound card or a regular DACConnect to power headphone amp You can connect the line out of D10s to the input of your ampl
