TC411+2TRA Needle Roller Thrust Bearings with Washers 1/4 Bore 11/16 OD 5/64 Width 28000rpm Limiting Speed 2pcs

Description: This Needle Roller Thrust Bearings provide a high degree of stiffness within a minimum axial space. It has a smaller cross-section than a standard thrust bearing for use in restricted spaces. These bearings to accommodate heavy axial loads and peak loads due to small diameter deviation of the rollers within one assembly. Thrust Bearings can be combined with washers in applications where adjacent components cannot serve as raceways. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment robotics elevators rolling mills ship rudder shafts and aggregate crushers among others. Specification: Bearing No.: TC411 Needle Roller Material: Chromium Steel (GCr15) Cage Material: ST14 Steel Bore Diameter (d): 1/4 / 6.35mm Outside Diameter (D): 11/16 / 17.4625mm Bearing Thickness (T1): 5/64 / 1.984mm Washer Thickness (T2): 0.8mm Total Thickness: 3.584mm Dynamic Load Capacity (Cr): 4114N Static Load Capacity (Cor): 9163N Maximum Rotational Speed (Oil): 28000rpm Number of Pack: 2 Pcs
