TB6600 Upgraded Stepper Motor Driver for 28/39/42/57 Stepper Motor 3D Printer Part

Features Automatic current halving at standstillCan drive 4 6 8 wire two phase and four phase stepper motorsOptocoupler isolated signal input strong anti interference abilityWith overheat overcurrent undervoltage lockout input voltage protection against reverse connection etc External signal 3 3 24V universal no need to connect resistor in seriesNote Do not connect the wrong 220V It is recommended to debug the dipswitch without powerSpecifications Humidity 40 90 RHVibration 10 55Hz 0 15mmStorage temperature 20 65℃Output current 0 5A 4 0AInput voltage 9 42VDCSize 97 58 30mmCooling method natural cooling or forced air coolingSignal input single ended pulse directionSubdivision optional 1 2 4 8 16 32 subdivisionUse motor current under 4 0A outside diameter 39 42 57mm four wire six wire eight wire two phase hybridstepper motor Package Included 1 x stepper motor driver
