TB6600 4.5A CNC Stepper Motor Driver Stepper Motor Controller Board for CNC Router Engraving Machine

Description 1 Operating voltage DC 10V 45V DC32V switching power supply is recommended 2 high speed optical coupling 6N137 ensure high speed without losing step 3 Toshiba s new high current high voltage TB6600HG new original chip there are low pressure shut off overheating parking and over current protection circuit short circuit protection and increased compared to TB6560 4 Rated maximum output reached ± 4 5A 5 for 4 2A 42 57 86 within the two phase four phase four wire six wire stepper motor 6 Automatic half current function 7 Subdivision full step half step 1 4 step step 1 8 1 16 step up to 16 segments Feature 1 The output current is steplessly adjustable to meet your various application requirements 2 Automatic half flow function It is also equipped with an automatic half flow switch which is easy to use 3 Using 6N137 high speed optical lotus root to ensure high speed without losing step 4 The subdivision setting instructions are printed on the back of the board 5 Use enlarged radiator good heat dissipation 6 With output short circuit protection function worry free use 7 Adopting the common anode input mode there are two input terminals the wiring is more convenient Specification Name TB6600 4 5A Stepper Motor DriverWorking voltage DC 10V 45V suggest to use DC32V switching power supply Rated maximum output ± 4 5AApplication Applicated to 42 57 86 two phase four phase four wire six wire stepper motorDimension 50 82 35mm Pa
