TB-RK3399Pro Development Board AI Artificial Intelligence Platform Deep Learning Firefly Android 8.1

Feature: Specification SOC RK3399 Pro CPU Big.Little architecture: Dual Cortex-A72 + Quad Cortex-A53, 64-bit CPU Frequency is up to 1.8GHz GPU Mali-T860MP4 GPU, OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, Open CL, DX11 Supports AFBC (ARM Frame Buffer Compression) NPU Support 8-bit/16-bit Inference Support TensorFlow/Caffe Model VPU 4K VP9 and 4K 10bits H265/H264 video decoders, up to 60fps 1080P other video decoders (VC-1, MPEG-1/2/4, VP8) 1080P video encoders for H.264 and VP8 Video post processor: de-interlace, de-noise, enhancement for edge/detail/color RGA Support real-time image scaling, cropping, format conversion, rotation and other functions Memory 3GB/6GB LPDDR3 Storage TF-card EMMC 16GB/32GB eMMC Dispaly HDMI2.0(Type-A) for 4K/60fps with HDCP1.4/2.2 DisplayPort 1.2(Type-A) up to 4K@60fps MIPI interface, support 1920*1080@60fps eDP1.3, support 2K@60fps Audio Support microphone, headphone, speaker 8 channels I2S supports 8 channels array microphone Wireless Network Support 2.4G WiFi, support 802.11b/g/n potocol Support Bluetooth4.2 Ethernet 10/100/1000Mbps Ethernet ( Realtek RTL8211E ) Camera Interface Support dual channel MIPI-CSI camera interface, (Maximum 13Mpixel or dual 8Mpixel) USB Interface 2*USB2.0 Host(Type-A) 1*USB3.0 Host(Type-A) 1*USB3.0 OTG(Type-C) PCI-E Interface 1*mini PCIe interface for LTE module 1*PCIe x4 interface support the expansion of high-speed WIFI, storage and other devices based on PICe SIM 1*SIM connector for extending LTE module with mini PCIe interface Debug 1*debug serial port (Micro USB interface) IO Interface 40pin IO interface: 8 channels I2S supports 8 channels array microphone 1*SPI interface 2*ADC interface 2*I2C interface 4*GPIO interface, support interrupt programming DC Power (12V, 3.3V, 5V) Power DC 12V/2A System Pre-installed Android and Linux system, support dual system boot and one-button OS switching PCB Size 145mm106mm >>>Wiki: Click here to open
