TAS5630 2.0 DC 48V 1200W High Power Digital Amplifier Board

Description OPA1632 is a fully differential amplifier for driving high performance audio analog to digital converter ADCs The highest audio quality which provides very low noise and output driver optimized for this application of gain bandwidth design OPA1632 180MHz 50V s and very fast conversion speed produce very low distortion 0 000022 input noise 1 3nV root Hz to further ensure the ratio and dynamic range and signal to noise Full differential structure flexibility can easily realize single ended differential output conversion Differential output decreased even harmonics ADCs provides high performance audio PCM1804 excellent performance drive to reduce common mode noise OPA1632 interference such as the use of shutdown function also enhances the flexibility TAS5630 amplifier is integrated analog input 300W stereo feedback total D class 600W amplifier capable of providing up to 300W stereo from a single supply 50V to 4 ohm speakers THD 0 03 Its SNR is greater than 100db PSRR is 80dB and the power level is up to 88 Features Use original TAS5630 OPA1632DR The main filter electrolytic capacitor adopts the capacity of 470UF 100V 8 to ensure strong and continuous power support The resistance uses five ring metal resistors and the main circuit uses a five ring metal film resistor with an accuracy of ±1 which ensures a good signal to noise ratio of the whole machine The use of high current inductors dedicated to red gray ring audio ensures a clear
