T8 500mm Lead Screw Set with Shaft Coupling and Mounted Ball Bearing

Description: T8 500mm Lead Screw Set with Shaft Coupling and Mounted Ball Bearing 2mm Lead Specification: Lead screw Material stainless steel Diameter 8mm Lead 2mm Total Length 500mm Screw nut Material: brass Diameter 8mm Mounted ball bearing Material zinc alloy Bore diameter 5mm Hole diameter 8mm Total length 55mm Height 29mm Shaft coupling Material aluminium Shaft 6.35 x 8mm Length 24mm Diameter 18mm Quantity 1 set ( 1 screw + 1 Screw nut + 2 Mounted ball bearing + 1 shaft coupling) Features: Screw mainly used in stepper motor, machine Tool, and other equipment. Screw without processing, direct connected to bearing. Lead screw was PVC tube packaging. Suitable for Industrial automation equipment, stepper motor rails; such as 3D printers; engraving machine; XYZ module; slider; lifts etc. How to install: 1. Put screw nut into the Lead screw. 2.Then the 2 Mounted ball bearing separately install at both ends of the Lead screw. 3. According to the size of you need to adjust the distance between the nut and Mounted ball bearing. 4. Put shaft coupling into the Lead screw beside the Mounted ball bearing. Package Included: 1 x Lead screw 1 x Screw nut 2 x Mounted ball bearing 1 x Shaft coupling More Details:
