T.RD8503.03 Universal LCD LED TV Controller Driver Board +7 Key button+1ch 6bit 40Pins LVDS Cable+Speaker+EU Power Adapter

Manual: http://myosuploads3.banggood.com/products/20181221/20181221025954SKUA79595.pdf Firmware: http://myosuploads3.banggood.com/products/20190305/20190305040218T.RD8503.031.rar Description: Model: T.RD8503.03 Tuner: RDA5160 Scheme of the chip: 8503 TV Format: Analog Signal Support Language: Russian, English, Hindi, Simplified Chinese, Khmer, Vietnamese, Myanmar, French, German, Italian, Spanish. Input Interface: PC / HDMI / TV / AV / USB multimedia playing Power Adapter: DC 12V 3-5A Screen interface: LVDS Single 6 Screen voltage: 3.3V / 5V / 12V (Jump cap) Resolution: Support high screen 1920 * 1080, 8.9-42 inch LVDS screen (support most of the panels, but not all) Not only USB interface can be used to upgrade programs, but also can use to play video/music/photo, basically, formats are supported. You can also set a boot display pictures or LOGO and Mirror Enable. How to know if your panel suitable for this board? Step 1: Find your LCD model's resolution (you can check the resolution from this link: http://www.panelook.com/index.php) Step 2: Find and write in the corresponding firmware. You can download the firmware from here: http://myosuploads3.banggood.com/products/20181221/20181221022350DANGKOURR52C04A.rar Programming: 1. Put the firmware of "SKR8503_100.bin" in formatted USB flash disk(FAT32) then insert the USB disk and the 7KEY-Button to the board 2. After turn on the power, the light of the 7key button be Red then flash red faster. IT KEEPS flashing and NEVER STOP. it's normal, just wait about 1 minute, it means upgrade has finished. then power off and pull off the u-disk. (Note that write programs do not power outages, crashing won't be able to use) Package included: 1 x Controller Board 1 x English Remote control 1 x IR 1 x 7key button 1 x 1ch 6bit 40Pins lvds cable 250mm length 2 x 4ohm 3W Speaker 1 x EU 12V 4A Power Adapter Note: The IR & KEY definition is special and different between v29 v56 v59 and 3463A, pls notice and don't mix up. This kit is just for signal interface is 1ch 6bit 40Pins and without inverter If you are not sure, pls provide your lcd panel model number to us so we can help you, thanks
