Surpass Hobby LED Program Card For 1/10 Crawler Brushed ESC With BEC 6V/2A

DECLARATION This is Electronic Speed Controller ESC for Crawler Brushed High power system for RC model is not good so please read this manual carefully Since we can t control over the correct use installation application or maintenance of our products we ve no liability shall be assumed nor accepted for any damages losses or costs resulting from the use of the product Any claims arising from the operating failure of malfunctioning etc will be denied We assume no liability for personal injury consequential damages resulting from our product or our workmanship FEATURES 1 Specially designed for RC Crawler Brushed car with excellent throttle linearity and driving feel 2 Compatible with brush motor 3 The strong resistant current capability excellent heat dissipation 4 Multiple protection features Low voltage cut off protection for lithium or nickel battery Over heat protection Throttle signal loss protection 5 Easily programmed and compatible with pocket sized program card Specifications1 Cont Current Burst Current 60A 320A 2 Resistance 0 0014ohm3 Motor Type brush motor 4 Suitable Car 1 10 Crawler Brushed 5 Battery 2 3 cells Lipo 4 9 cells NiMH 6 BEC 6V 2A switch mode 7 Dimension 32mm 37mm 18mmInstuctions1 Connect BEC wires with the receiver2 Connect motor wires with ESC3 Turn on the transmitter4 Connect battery pack with ESC then switch on the ESC 5 When the connection of motor and battery is finished the motor emits Beep tone 6 Whe
