Surpass Hobby KK 3674 2250KV Brushless Motor 120A Brushless ESC 15KG Digital Servo Brushless Set for 1/8 RC Car Model Pa

Surpass Hobby KK 3674 2250KV Brushless Motor 120A Brushless ESC 15KG Digital Servo Brushless Set for 1/8 RC Car Model Pa
SURPASSHOBBY
sku: 1936507
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$88.99
Shipping from: China
   Description
Description Item Brand Surpass HobbyItem Number 3674 2250KV Brushless Motor 120A ESC With 15KG Digital Servo Item Name RC car motor esc setMaterial Metal and plasticColor Black and RedThe Size of the Motor Length 74mm diameter 36mm shaft diameter is 3 175mm length of extended shaft is 17mmThe Size of the ESC 40 32 15mmThe Weight of the Motor ESC About 352g 33gFit For 1 10 1 8brushless rc carsThe Specification of the Motor KV2250KVWatts 1800Max Voltage 22 2VMax Amps 80ARotor Poles 4IO 4 0AResistance 0 0076Max RPM 50000Connector 4 0mm goldThe Specification of the ESC Cont Current 120ABurst Current 600AMotor Type Sensorless Brushless MotorFor 4s Lipo or 12 cells NiMH1 On road 40XX size or smaller motor with the kv 30002 Off road buggy monster 40XX size or smaller motor with the kv 2500For 6s lipo or 18 cells NiMH1 On road 40XX size or smaller motor with the kv 25002 Off road buggy monster 40XX size or smaller motor with the kv 2000Suitable Car 1 8 carResistance 0 00035ohmBattery 3 6 cells lipo 9 18 cells NiMHBEC Output 6 1V 3A switch mode For the esc manual please click here15KG Metal ServoModel S1500MType DigitalGear MetalHorn gear spline 25TRated torque ≥15kgf cmMax torque ≥23kgf cmVoltage 7 4VNo load speed ≤0 23S 60°Size 40 4 20 38 6mmWeight 62gFeatures 4 Pole 12 Slot Hi torque Motor DesignCNC Machined 6061 T6 Billet Aluminum Heatsink CanHigh Purity Copper Windings Maximizes EfficiencyHigh RPM ABEC5 Oversized BearingsUniversal fit fits all 1 8 1 10 brushless cars multi m
