Sunhans 3000mW 35dBm 2.4GHz 11b/g/n Wireless WiFi Signal Booster Signal Amplifier

Sunhans 3000mW 35dBm 2.4GHz 11b/g/n Wireless WiFi Signal Booster Signal Amplifier This indoor signal booster can increase the effective range and coverage area of your Wi-Fi network. It is Ideal for increase the 2000-2500Mhz frequency devices. Description: Model: SH24BTA-N P/N: 24BTAN24014 Barcode: 6958917600827 Operating range: 2400~2500MHz Channel width: 20Mhz&40Mhz Supported standards: IEEE 802.11b/g/n Operation mode: Bi-directional, half-duplex, time division duplex Connector type: To radio SMA female (hole inside). To antenna RP-SMA male (pin inside) Output power: 3000mW (35dBm) Input power: 0 ~ 20dBm Transmit gain: 15 - 18dB Receiver gain: is less than or equal to 12dB Noise figure: = 3.5dB typical Frequency response: + 1dB over operating range Power adapter: 12V/2A DC, 100~240V Operating temperature: -20 C to +70 degrees C degrees Operating humidity: Up to 75% relative humidity Material: Cast aluminum LED light: Power status LED and activity status LED Booster weight: 150g Booster size: 8.4 x 4.7 x 1.7cm Package weight: 450g Package size: 21.3 x 13.5 x 5cm Use Step 01: Remove the Antenna from the Wireless Router (Access Point). Step 02: Use this cable (RG316) to connect Amplifier 'input' port with router 'output' port: note that cable is in standard spec. Step 03: Connect the antenna with 'output' port of Amplifier. Step 04: Power the amplifier with the matching source adapter: DC 12V. Attention: The power amplifier is not suitable for use in high power devices Package Included: 1 x SH24BTA-N Wifi Signal Booster 1 x RG316 cable with SMA connectors (20cm) 1 x 6dBi omni antenna 1 x power supply 1 x user manual
