Sufanic Fy2300 20mhz Dual Channel Dds Arbitrary Waveform Signal Generator Signal Source

Features: 1.Adopts DDS direct digital synthesis technology can generate precise stable output signals with higher distortion. 2.With high quality aluminium alloy shell and powered by DC 5V convenient and portable for use. 3.Can output arbitrary waveform and conventional function waveform (sine/triangle/square/sawtooth wave signal). 4.All functions are digitally controlled precise and stable. 5.2.4 (320*240)color display simultaneously display dual-channel waveform parameters. 6.The highest output frequency(sine wave) is up to 20MHz 200MSa/s sampling rate and 12 bits vertical resolution. Waveform Length:2048Points Sampling Rate:200MSa/s Vertical Resolution:12 Bits Sine Wave: Harmonic Arrived System:≥45dBc(3Vpp Fan-out:>20 TTL Load CMOS Output Low Level:10MHz) Waveform Output: Output Impedance:50Ω(+/-10%) (Typical) Protection:All signals output can work above 60s under the condition of load short circuit DC Bias: Bias Adjustment Range:(+/-)10V Bias Resolution:0.01V External Measurements: Frequency Measuring Range:GATE-TIME=1S 1Hz - 60MHz Input Voltage Range:0.7Vpp~20Vpp Counting Range:0~4294967295 Counting:Manually Periodic Measurement:20ns Resolution the Max. Measurable 40s Scanning Function: Scan Mode:Linear Sweep Log Sweep Scan Object:Frequency Amplitude Bias and Duty Cycle Scan Time:0.01s-999.99S/Step Frequency Setting Range:Start Point and End Point can be set freely Frequency Scan Range:It is determined by the sweep parameter settings General Parameters: Memory Quantity:20 Location:M0~M19 Interface Interface Mode:Using USB to Serial Interface Communication Rate:9600bps Protocol:Using the Commands Line the Agreement Public Power Supply Voltage Range:DC 5V (+/-0.5V) Display Display Type:2.4 TFT Color Display Environment Temperature: 0~40°C:Humidity:
