StarTech 4 Port RS232 PCI Serial Card Adapter with Power Output

The PCI4S954PW 4-Port PCI Serial Card (with Power Output) turns a PCI slot into 4 RS232 (DB9) serial connections and enables compatible devices to draw power from the serial ports. Suitable for many RS232-powered serial applications, this PCI serial card offers a selectable 5V or 12V power option, capable of power output using pin 1, 4, 8 or 9, which enables you to configure the card to suit the requirements of your powered RS232 devices. A flexible solution for adding serial ports to full-sized or small form factor systems, the 4-port serial card includes both low and full profile brackets while the included breakout cable helps to avoid cluttered connections. Backed by a StarTech Lifetime warranty and free lifetime technical support. • Four high speed RS232 serial ports with data transfer rate up to 460 Kbps • Selectable voltage output of 5V or 12V • Selectable power output via pin 1/4/8/9 • Universal PCI card supports installation into 3.3 or 5V PCI slots • Compliant with PCI specifications revision 3.0 • High Performance Oxford 16C950 UART • 128-byte deep FIFO per transmitter and receiver • +/-15KV ESD protection on all signal pins Advantage • Selectable 5/12V power output on one of four different pins provides the flexibility needed to connect nearly any powered serial device • The included breakout cable saves expense as an all-in-one solution and allows the addition of multiple RS232 serial ports through a single PCI slot • Includes both low profile/half-height and full profile brackets to ensure fitment into a broad range of system form factors Applications • Monitor and control industrial machines on an assembly line or in a production environment • POS retail applications in grocery stores and any other retail store to control keyboards, cash drawers, receipt printers, card readers/card swipes, scales and elevated displays on poles • Bank teller workstations in either full profile or low profile versions to control their serial devices such as cash drawers, card readers / card swipes, printers, keypads / pinpads, pen pads • Self-service automated machines and kiosks to control serial devices such as scales, touchscreens, magnetic card readers, bar code scanners, receipt printers, label printers • Used to control multiple surveillance / security cameras in a parking structure, office building, etc. • Standard ATM automated teller machines to control keypads, receipt printer, card readers / card swipes, touchscreen LCD's, camera control, etc.
