StarTech 2 Port Low Profile Native RS232 PCI Express Serial Card with 16950 UART

The PEX2S952LP low profile/half-height PCI Express Serial Card turns a PCI Express slot into two RS232 (DB9) serial connections. The card is constructed using a native single chip design that lets you harness the full capability offered by PCI Express (PCIe), while reducing the load applied to the CPU by as much as 48% over conventional bridge chip serial cards.The PCI Express RS232 Serial Adapter Card is compatible with a broad range of operating systems including Windows 7/ Server 2008 R2 / Vista/ XP/ 2000, Linux Kernel 2.6.11 and up. The card comes pre-configured with a low profile bracket, but also includes an optional full profile bracket that lets you add two serial ports to virtually any computer (regardless of the case form factor). Backed by a StarTech Lifetime warranty and free lifetime technical support• 128-byte deep FIFO per transmitter and receiver • Automated in-band software flow control using programmable Xon/Xoff in both directions • Automated out-of-band hardware flow control using TX/RX/RTS/CTS/DSR/DTR/DCD/RI/GND • Compliant with PCI Express base specifications revision 1.1a • High Performance Dual Channel Oxford 950 UART • Native single-Chip, single lane PCI Express • Selectable power output on pin 9 for the serial port • Two high speed RS-232 serial ports with data transfer rate up to 460.8 Kbps • Ships with half-height mounting bracket; includes optional standard bracket Advantage • Data transfer rates of up to 460 Kbps for peak serial device performance • Native single-Chip, single lane PCI Express offers increased performance, for up to 48% less cpu load • Pre-configured for Low profile systems but includes a full profile bracket for versatility Applications • Bank teller workstations in either full profile or low profile versions to control their serial devices such as cash drawers, card readers / card swipes, printers, keypads / pinpads, pen pads • POS retail applications in grocery stores and any other retail store to control keyboards, cash drawers, receipt printers, card readers / card swipes, scales and elevated displays on poles • Self service automated machines and kiosks to control serial devices such as scales, touchscreens, magnetic card readers, bar code scanners, receipt printers, label printers • Standard ATM automated teller machines to control keypads, receipt printer, card readers / card swipes, touchscreen LCD's, camera control, etc. • Used to control multiple surveillance / security cameras in a parking structure, office building, etc.
