Sony PVM-X2400 V2 24" 4K HDR TRIMASTER High Grade Picture Monitor

The PVM-X2400 is a 24-inch 4K HDR high grade picture monitor, incorporating a Sony-specified premium LCD panel that offers 1000 cd/m2 luminance and color matching with the BVM-HX310 4K HDR master monitor. This makes group monitoring easy in on-set, studio and OB van walls, and in 19" EIA racks for editing, audio mixing etc.TRIMASTER assures accurate color reproduction, precise imaging and consistent picture qualitySony's acclaimed TRIMASTER architecture delivers accurate picture reproduction, precise imaging and quality picture consistency. There are many advantages in the panel control and signal processing system such as fast processing, accurate linearizing of an input signal with Optical Electrical Transfer Function, accurate color reproduction, etc.HDR-SDR conversion supportWith V2.0 firmware and optional PVML-HSX1 HDR-SDR conversion license, the PVM-X2400 supports HDR-SDR conversion in live production environments. The license activates 4K to HD down-conversion, color space conversion and OETF conversion. It also allows output of converted pictures to another 4K or HD monitor from the Enhanced Monitor Output. This function can be used at a remote sites fed only by an HDR signal.Live production metadataThe PVM-X2400 offers support for live production metadata, allowing confirmation if input source settings and monitor settings are matched.Dynamic Contrast Drive and Black Detail High / Mid / LowDynamic contrast drive adapts backlight luminance to suit the scene, achieving a 1,000,000:1 dynamic contrast ratio. Total balance of highlights and low lights can be confirmed at a glance. Due to the mechanism of LCD panels, backlight leaking from the panel surface is unavoidable. Black Detail mode provides more accurate monitoring of black details in dark, low-APL (average picture level) images.Inputs for 12G-SDI and Quad-Link 3G-SDI to HD-SDI as well as HDMIThe PVM-X2400 can accept 12G-SDI from latest sources, and can input quad-link 3G-SDI and a single HD-SDI from traditional devices. This input utility is HDMI supports from 640x480/60P PC signal to 4096 x 2160/60P 4:2:2 YCBCR 12bit.Various scopesWaveform monitor and vector scope can be simultaneously displayed with scales for both HDR and SDR, allowing conveniently checking of both input signal level and output luminance by the HDR scales of the waveform monitor. There are three different displays for luminance, RGB/YCBCR parade or RGB overlay with the gamut error display. The waveform of a specified line can also be displayed.Unique quad view display with User 3D LUTThe PVM-X2400 provides a quad view display, with individual settings for EOTF (SDR/HDR), color space, transfer matrix, color temperature, contrast, brightness, SDI/HDMI, RGB/YCBCR, as well as User 3D LUTs for each display view.Enhanced user interface and channel select buttonThe monitor's OSD has been signiciantly enhanced to make operation even quicker and more intuitive. Design of the menu allow review and quick adjustment of settings. The Channel select button protects users from making inadvertent setting errors.Optimised features for field operationDC 24V operation allows field-based operation, despite the monitor's large 24" screen size and very high 1000 cd/m2 luminance. An optional protection panel protects the premium LCD screen from inadvertent shocks. User 3D LUTs and yoke-mounting are also supported. Dynamic Contrast Drive is particularly valuable when shooting night scenes. Field operation is further enhanced by false color and camera focus function.Various mount capabilitiesDespite its large 24-inch screen size, the PVM-X2400 can be installed to 19-inch EIA standard rack in studio and OB van environments. Yoke-mount and VESA mount options are also convenient for installation in a C stand for field use, or on a desktop arm for editing.Powerful stereo sound with audio mutingThe PVM-X2400 incorporates stereo speakers (2W+2W) with audio muting.Features24-inch 4K premium LCD panel for faithful color matching with BVM-HX310The PVM-X2400 features a 24-inch 4K premium LCD panel (3840 x 2160 pixel resolution) with a wide color gamut, high luminance, high contrast, fine gray scale, wide viewing angle and excellent uniformity. The Sony-specified panel achieves 1000 cd/m2 luminance and 100% color gamut, corresponding to the industry-leading Sony BVM-HX310 Master Monitor. This provides an accurate color matching value in the entire production workflow from camera shooting to finishing in applications including live productions, TV programmes, documentaries, music videos, movies, drama and commercials. All personnel working on a project can reliably share the same accurate view of colors and tones, even if they are working at different locations and times.TRIMASTER assures accurate color reproduction, precise imaging and consistent picture qualitySony's TRIMASTER architecture offers accurate picture reproduction, precise imaging and quality picture consistency. The panel's control and signal processing system offers significantly advantages including fast processing, accurate color reproduction and accurate linearising of input signals with Optical Electrical Transfer Function.HDR-SDR Conversion supportWith V2.0 firmware and the optional PVML-HSX1 HDR-SDR conversion license, the PVM-X2400 supports HDR-SDR conversion in a Live production system. The HDR license activates 4K to HD down-conversion, color space conversion from ITU-R BT.2020 to ITU-R BT.709, and OETF conversion from HDR EOTF S-Log3(HDR), ITU-R BT.2100(HLG), SMPTE ST2084 to SDR EOTF 2.4. It also allows output of converted pictures to another 4K or HD monitor from the Enhanced Monitor Output that supports 12G or 3G-SDI, even though an original 4K source is Quad link 3G-SDI. This function can be used at a remote site that can only be fed an HDR signal.Supported with V2.0.PVML-HSX1 HDR-SDR conversion license available separately. Monitor must be updated to v2.0 firmware or later. HDR-SDR conversion is activated via the USB port on the front control panel of the monitor.Live production metadataThe PVM-X2400 offers support for live production metadata, allowing easy comparison if settings of an input source and monitor settings are matched to each other. This feature enables faster, smoother on-site preparation of live production projects.Dynamic Contrast DriveSony's Dynamic Contrast Drive backlight driving system dynamically changes backlight luminance according to the scene to achieve a dynamic 1,000,000:1 contrast ratio. This allows at-a-glance checking of the total balance of highlights and low lights. As a further advantage there is no artificial halo effect caused, and each signal level is displayed as the same display luminance.Black Detail High/Mid/LowBacklight leaking from the panel surface is a consequence of LCD panel designs. Black Detail mode provides more accurate monitoring of black details in dark, low-APL (average picture level) images. Black level is reduced, but gamma is maintained for correct color and gray scale. However, high luminance areas are clipped due to the dynamic range of the monitor. The portions to be clipped can be displayed either by zebra patterns or clipped image.Versatile 4K video input capabilityThe PVM-X2400 is equipped with built-in standard input interfaces: (12G/6G/3G/HD-SDI) BNC (x2), (3G/HD-SDI) BNC (x2) and HDMI (HDCP2.3/1.4) (x1). 12G simplifies wiring, from simple to large-scale field systems. Quad-link 3G-SDI is highly convenient for systems configured with 'traditional' devices. HDMI simplifies interfacing with devices including rasterizer, multi-viewer, digital camera, set top box, UHD Blu-ray, PC etc.Various signal settings and automatic setting by Video payload IDManual signal settings include ITU-R BT.2020, ITU-R BT.709, DCI-P3, S-Gamut/S-Gamut3, S-Gamut3.Cine as color space and ITU-R BT.2100(HLG), SMPTE ST 2084, S-Log3 and S-Log3(Live HDR) as EOTF. In addition, support for VPID (Video Payload ID) can identify EOTF, color space and RGB source information embedded in the SDI signal. Monitor settings are adjusted automatically, cutting the risk of human error in pressured live production environments.4K/HD scopes with HDR/SDR scale and audio level meter displayBoth waveform monitor and vector scope can simultaneously be displayed with scales for either HDR or SDR. Scales are automatically changed according to a selected EOTF setting of the monitor. You can conveniently check both input signal level and output luminance by the HDR scale of the WFM. Various modes include a zoom function (in an area of either 0 - 20% or 0 - 30%) with the waveform monitor, and a zoom function in the central black area with the vector scope, for adjusting camera white balance. The waveform has three different displays of either luminance, RGB/YCBCR parade or RGB/YCBCR overlay with the gamut error display. The waveform of a specified line can also be displayed. In addition, an audio level meter can display embedded audio signals from the SDI or HDMI input. It can display on screen either Ch1-8 or Ch9-16.Unique Quad View displayThe PVM-X2400 provides a Quad View display mode with individual settings of EOTF (SDR/HDR), color space, transfer matrix, color temperature, contrast, brightness, user LUT, SDI/HDMI and RGB/YCBCR for each display view. Different HD input sources can be compared as a part of an HD wall
