Sony PDW-F75 3.5" LCD XDCAM HD Deck

The Sony PDW-F75 XDCAM HD decks are highly versatile and can be used for many different applications including HD video recording, linear/nonlinear editing and presentations at large exhibitions and conference venues. The PDW-F75 XDCAM is highly flexible and can record in both MPEG HD and DVCAM formats. It is capable of recording 1080 video lines of multiple frame rates at a high bit rate of up to 35 Mbps on Professional Disc media. It also provides four channels of high quality uncompressed audio. The PDW-F75 deck records and plays Professional Disc with HD material at 1080/59.94i, 50i, 29.97P, 25P and native 23.98P using the "MPEG HD" codec that uses the industry standard MPEG-2 MP at HL compression. And for high quality sound, four channel, 16 bit, 48 kHz uncompressed audio is used. The deck also can down-convert MPEG HD material to DV signals and outputs via the i.LINK interface. The PDW-F75 also features a built-in Up/Down-conversion to up-convert DVCAM material to HD signals and output via HD-SDI or HD analog component connection as well as to down-convert MPEG HD material to SD SDI or composite connection. It supports Jog/Variable operation with +/- 1 times normal speed and Shuttle with +/- 20 times normal speed even adopting MPEG Long GOP. In the thumbnail operation, the Expand function displays 12x further detail around a scene, which the operator can see in the clip, on top of Scene Selection, commonly known as in-deck cuts-only editing capability.
