Sony 22RU Multi-Bit Rate Router Frame

The Sony HDS-X5800 Router is an ultra-compact 22 RU multi bit-rate router developed to support every format defined by Rec ITU-R BT605, SMPTE259M (SD) and SMPTE292M (HD) as well as 1080/24P format and DVB/ASI signals. Up to 264 inputs and 272 outputs handle signals from 143 Mb/s up to 1.5 Gb/s. Can be expanded up to a 1056 x 1088 matrix by cascading multiple frames. Auto re-clocking at 143 M, 177 M, 270 M, 360 M, 540 M, 1.485/1.001 G and 1.485 Gb/s. Router control is via S-BUS and RS-422A. S-BUS is providing communications and tally management with BKS-R Series routing switcher control units, Sony MVS/DVS Series production switchers and so on. Among the many features that S-BUS supports are multi-level working, signal breakaway, phantom operation of cross-points and tie-line management. Router data is maintained in memory by a 24-hour battery backup. Ethernet-based remote control and setup.
