Sonnet 750ex eGPU Breakaway Box

Add a High-performance Video Card to Create Your Own Personal eGPU WorkstationTransform Your Thunderbolt Computer Into a Graphics WorkstationWhether you're editing, rendering, color grading, animating or creating special effects, many of the pro applications you use rely on desktop and workstation graphics (GPU) cards to do the heavy lifting in processing data. Unfortunately, many popular computers are equipped only with integrated graphics or low-power discrete GPUs that bottleneck performance when performing these tasks. Happily, there's a simple path to greater productivity-add a Sonnet external GPU (eGPU). The eGPU Breakaway 750ex Thunderbolt to GPU PCIe card expansion systems boost your eGPU-compatible computer's graphics performance by connecting a high-performance GPU card to your computer via a single cable.
Future-proof UpgradeWith each new generation of GPU cards, users can look forward to a step (or leap) forward in performance. Less predictable is how much power they will require to operate-better performance frequently requires increased power. For eGPU users, power consumption can be a concern. Don't limit your future video graphics card choices-choose a Sonnet eGPU Breakaway 750ex. Equipped with 750W power supplies, these Sonnet chassis easily support the highest power demands of latest GPUs and have plenty of extra power to support GPU cards from generations to come.

Both eGPU Breakaway Box models are Thunderbolt Certified and include a Thunderbolt 3 cable to connect the system to your computer. The 750ex provides a handy connection hub for USB devices and Ethernet connectivity.
No Compromise GPU Card ChoiceeGPU Breakaway Box 750 systems are designed specifically to accommodate the most power-hungry double-width GPU cards. They support Thunderbolt-compatible cards(1) with popular GPU chipsets-such as AMD Radeon RX series (including VEGA GPUs); and NVIDIA GeForce series and TITAN GPUs. Even the latest pro cards-AMD Radeon Pro and NVIDIA Quadro GPUs-are supported! (Note that macOS supports only AMD GPU cards in eGPU systems, while Windows supports AMD and NVIDIA cards.) With a GPU card installed, a Breakaway Box functions as a simple plug-in upgrade to significantly accelerate the demanding needs of your video production workflow.

Boosts Graphics Performanceonnects a high-performance GPU card to your computer with Thunderbolt 3 or Thunderbolt 4 ports.

Cuts Application Task TimesEnables GPU acceleration to significantly improve editing, rendering, color grading, animation, and special effects performance.

750W Power SupplySupport the power requirements of the latest compatible GPU cards; future-proof design handles higher power requirements of cards to come.

Supports Many of the Latest GPU CardsIncludes AMD Radeon VII, RX, RX Vega, Pro W and Pro WX models; and NVIDIA GeForce RTX series, TITAN, and Quadro models.

Multi-eGPU Acceleration SupportConnect two, three, or four eGPU Breakaway Boxes to slash task times on supported applications.

Supports Non-GPU PCIe CardsSupports Thunderbolt-compatible full-length, full-height, single- or double-width cards -perfect for pro audio I/O and DSP cards and pro video I/O and transcoding cards.

Quietest Configurable eGPU System AvailableLarge built-in, variable-speed, temperature-controlled fan quietly and effectively cools whatever card you install.

Choice of ModelsBoth models support the same GPU cards, include the same power supply, and provide the same portable computer charging support; the 750ex adds additional connectivity.

750ex Model: Additional ConnectivityAdds four 5Gb/s USB Type A ports to connect peripherals, plus an RJ45 Gigabit Ethernet port for a wired network connectivity.

Single-Port 40Gbps Thunderbolt 3 InterfaceEnsures full 2750 MB/s of PCIe bandwidth is dedicated to the installed card.

Thunderbolt CertifiedCertified for Thunderbolt for use with Mac computers.

Mac and Windows CompatibleCompatible with Mac and Windows computers with Thunderbolt 3 or Thunderbolt 4 ports.

4K to 8K Workflows -Connect Two or More Breakaway BoxesMany task times on supported applications-such as Adobe Premiere Pro, DaVinci Resolve, and Maxon Cinema 4D, to name a few-can be cut significantly with one eGPU Breakaway Box connected. But, for computers with multiple Thunderbolt ports, times can be slashed when two, three, or four Breakaway Boxes are employed. Connecting one or more eGPUs can multiply your computer's graphics processing power, enabling it to handle 4K, 5K, 6K, and 8K workflows more efficiently. Plus, a computer's onboard discrete GPU also contributes to the aggregate performance.

More Ports, Additional Functionality: eGPU Breakaway Box 750exIs your computer short on ports for basic connectivity? Step up to the eGPU Breakaway Box 750ex to add four 5Gb/s USB 3.2 Gen 1 Type A ports to connect peripherals, plus an RJ45 Gigabit Ethernet port for a wired network connection. The 750ex features a dual Thunderbolt controller design, enabling it to support both peripherals and GPU card through the single Thunderbolt connection to your computer.

Designed for GPU Cards, Also Supports Other Demanding PCIe CardsThe Breakaway Box's single x16 PCIe 3.0 slot accommodates full-length, double-width cards, and its 750W power supply supports trouble-free operation. Its single-port 40Gbps Thunderbolt 3 interface ensures the full 2750 MB/s of PCIe bandwidth(2) is dedicated to the installed card.

Coolest & Quietest Add-your-own-card eGPU System AvailableWith its large variable-speed temperature-controlled fan that quietly and effectively cools the installed card, the eGPU Breakaway Box can be comfortably used in noise-sensitive working environments.

Graphic-Intensive Gaming SupportThere's no need for you to carry a heavy, loud, and hot-running gaming laptop to have a great gaming experience-just plug in a Breakaway Box and add the GPU power you want when you need it! A Breakaway Box is ideal for empowering graphic-intensive gaming on an Intel processor-based MacBook Air or 13-inch MacBook Pro, Ultrabook and other thin/light notebook computers that otherwise would deliver a poor gaming experience. Accelerated graphics can either be displayed on one, two, or more external monitors, or on your notebook's own display panel(4). Best of all, you can upgrade the GPU card in the Box to keep up with the latest in GPU technology (unlike with gaming laptops).• Add GPU Power to Mac and Windows Notebooks with Intel Integrated Graphics• Experience Amazing Gaming on Your Notebook's Screen or an Expansive Multi-monitor Set-up• Upgradeable - Plug in a New Card to Stay Current with GPU Technology

Forward Compatible with Thunderbolt 4 ComputersThe eGPU Breakaway Box 750 and 750ex are fully compatible with Thunderbolt 4 computers and were purposely designed with a Thunderbolt 3 controller and its four lanes of PCIe (not available in a Thunderbolt 4 peripheral) to achieve maximum performance.
