Solar Energy Controller Normally Open 150W 10 12V MPPT Solar Controller For Panel WS M150 13.8V Normally Open

Solar Energy Controller Normally Open 150W 10 12V MPPT Solar Controller for Panel WS M150 13.8V Normally Open Specification: Item Type: MPPT Solar Controller Material: Plastic Normally Open: 24 Hours Load Output Efficiency: Greater than or equal to 95% Noise: 17V PV Input Tracking Voltage: 16 to 25V Output to Battery Current: 10A Maximum 12A No Load Loss: 20MA Voltage Adjusted Rate: 1% No Load Adjusted Rate: 5% Full Load Ripple: 400mV No Load Ripple: 100mV Discharge Module: Input Voltage: Equal to Battery Voltage Load Output Voltage: Equal to Battery Voltage Load Output Current: 10A Static Power Consumption: 12mA Load Output Mode: Normally Open Protection Module: Battery Short Circuit Protection: Yes Load Short Circuit Protection: Yes Temperature Protection: Yes Anti Backflow Protection: Yes Protection Level: IP67 Operating Temperature: Minus 40 degrees Celsius to +65 degrees Celsius Overheating Protection: when the Internal Temperature of the Mppt Controller Exceeds 100 degrees Celsius the Mppt Controller Will Reduce the Output Power. if the Internal Temperature Continues to Rise to 110 degrees Celsius the Mppt Controller Will Automatically Turn off the Output. when the Internal Temperature of the Mppt Controller is Lower Than 90 degrees Celsius the Mppt Controller Will Automatically Resume Operation. Package List: 1 x MPPT Solar Controller Note: The MPPT controller should be fixed on an iron or metal bracket to avoid the vibration of the machine due to instability. The MPPT controller should allow some space around the enclosure. Output and input wires should be kept as short as possible to avoid excessive energy dissipation during transmission. There is high voltage and high current in the machine and non‑professionals are not allowed to disassemble. The input and output terminals should be reliable and not loose so as to avoid heating at the connection point.
