Small BUCK DC-DC Adjustable Power Supply Non-isolated Set-Down Module Board, 501 Original

Small Model High Efficiency BUCK DC-DC Adjustable Power Supply Non-isolated Set-Down Module BoardFeature:1. This model is made of imported main control chip, which fixes 1.2MHZ oscillation frequency and uses ultra-low on-resistance (Ron) MOS tube internally. The overall work is stable and efficient.2. This module has the functions of over-temperature protection and over-current protection, which can ensure the safety of the use of electrical appliances and modules.3. This module is very small, only 20*20*5 (length, width and height) and weighs less than 10 grams. It is very suitable for large current and small volume applications, such as aeronautical models.4. This module uses machine patch and reflow welding. At the same time, each module undergoes two hours of aging test before shipment to ensure high reliability.Specification:Modular nature: non-isolated buck (BUCK)Input voltage: 4.75V-24VOutput voltage: 0.92V-15VOutput current: 2A (maximum)Conversion efficiency: 95% (maximum)Switching frequency: 1.2MHzOutput ripple: 30mV (maximum)Load adjustment rate: ±0.5%Voltage adjustment rate: ±2.5%Working Temperature: -40℃ to +85℃Rectifier: Asynchronous RectifierPackaging size: 80mm*60mm*5mm/3.14*2.36*0.19''Packing weight: 3gNote:Please allow 1-3mm differs due to manual measurement.Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.1 x Adjustable Power Supply Set-Down Module
