Sloan 3250401 G2 8186-1.0 Exposed Sensor Urinal Flushometer 1 GPF Chrome Fixture Connection Top Spud Single Flush Battery

Sloan 3250401 G2 8186 Exposed Flushometer Specifications Flush Volume: 1.0 gpf (3.8 Lpf) Finish: Polished Chrome (CP) Power Type: Battery Battery Life: 6 years Valve: Diaphragm Valve Body Material: Semi-red Brass Fixture Type: Urinal Fixture Connection: Top Spud Rough-In Dimension: 11-1/2 (292mm) Spud Coupling: 3/4 (19mm) Supply Pipe: 3/4 (19mm) ADA Compliant cUPC Certified BAA Compliant Sloan 3250401 G2 8186 Exposed Flushometer Features Sweat Solder Adapter with Cover Tube and Cast Set Screw Wall Flange Handle Packing Main Seat Stop Seat and Vacuum Breaker Molded from PERMEX Rubber Compound for Chloramine resistance Low Battery Flashing LED Infrared Sensor with Multiple-focused Lobular Sensing Fields for high and low target detection Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation Flex Tube Diaphragm designed for improved life and reduced maintenance Engineered Metal Cover with replaceable Lens Window Four (4) Size AA alkaline Batteries included Courtesy Flush Override Button 3/4 I.P.S. Screwdriver Bak-Chek Angle Stop with Vandal Resistant Stop Cap PERMEX Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass Sloan G2 exposed sensor urinal flushometer. - 1.0 gpf polished chrome finish fixture connection top spud single flush battery operated. Recommended Specification Valve Body Cover Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi- Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2. VALVE OPERATING PRESSURE (FLOWING) 15 – 80 PSI (103 – 552 kPa). Specific fixtures may require greater minimum flowing pressure - consult manufacturer requirements. Sloan 3250401 G2 8186 Exposed Flushometer Documentation BIM Model Brochure Installation Instructions Repair & Maintenance Guide Maintenance Schedule Information Sheet CAD Drawing CAD Drawing
