Skyzone RC708 5.8G 40CH Auto Search Diversity RX 7 Inch Monitor with HD Port DVR Ppm For RC Drone

Description: User Manual Brand Name: Skyzone Item Name: RC708 Display Diagonal 7 inch Resolution 800X480 Contrast 500:1 Luminance 500cd/ Wireless Receiver ISM 5.8GHz 40 Channel, Diversity receiver. Operating Frequency Band CH 1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 A 5865M 5845M 5825M 5805M 5785M 5765M 5745M 5725M B 5733M 5752M 5771M 5790M 5809M 5828M 5847M 5866M E 5705M 5685M 5665M 5645M 5885M 5905M 5925M 5945M F 5740M 5760M 5780M 5800M 5820M 5840M 5860M 5880M R 5658M 5695M 5732M 5769M 5806M 5843M 5880M 5917M Sensitivity -90dBm1dBm Antenna port 2 X SMA,50ohm Diversity receiving Antenna diversity PPM Remote control 3.5mm3P PPM 8 channel format Output Channel Optional 5CH,6CH,7CH, 8CH Record Micro SD Support to 32GB Compression MJPEG, 30fps, AVI Picture JPEG Record rate 6Mbps AV Signal Video Standard NTSC/PAL Video output level 1.0Vp-p Typ. / 75ohm Audio output level 1.0Vp-p Typ. / 10Kohm Built-in Speaker 8/1W AV Port Div. AV OUT(3.5mm4P) Diversity Video, Audio output AV IN(3.5mm4P) Video Audio input HD Port IN (A Type, HD multimedia interface 1.4a) 1920x1080p50/ 60, 1920x1080i50/ 60, 1280x720p50/ 60, 720x480p50/ 60, 720x480i50/ 60, 720x576p50/ 60, 720x576i50/ 60 Power Supply DC IN DC 7-28V/ 1A Power Consumption 12V input: 5.4W Dimensions Main Body 184X120X21.5mm(not include Sunshield) Battery 86X63X12 mm Weight 431g Tripod interface General 1/4 "thread Operating Temperature 0-+60 Features: 40 channels compatible with fatshark, Immersion rc, DJI Inspire /phantom HD Port video input compatible with DJI products 2800mA 7.4V integrated Li-po battery can charge when the monitor is power on. 500cd/m2 high brightness can watch clearly under the sun PPM function makes it can control camera from the monitor Build-in diversity system that will automatically receive the best video signal 431g (with battery) is the lightest 7 inch monitor in the market 2.15cm thick is the thinnest monitor in market so far. Usb plug can connect with other monitor, PC Micro SD card slot support TFT card till to 32GB A composite audio video input to display external sources Anti reflective matte screen and rubber coating Channel selection via button (no more micro switch.) Built in speakers (from your video Tx or video input sources) Package Included: 1 x Monitor 1 x Battery 1 x Sunshade 1 x Charging Cable 1 x AV Cable
