Skystars G730L 300mm F4 OSD 50A BL_32 7 Inch FPV Racing Drone w/ Runcam Swift 2 WDR Camera PNP

Skystars G730L 300mm F4 OSD 50A BL_32 7 Inch FPV Racing Drone w/ Runcam Swift 2 WDR Camera PNP Specification: Brand Name: Skystars Model: G730L Item Name: 300mm F4 OSD 7 Inch FPV Racer Version: PNP ( without receiver, battery and radio transmitter) Wheelbase: 300mm Arm Plate Thickness: 4mm TOP&Bottom Plate Thickness: 2mm Side Plate Thickness: 2mm Material: 3k Carbon Fiber and Aluminium alloy Net Weight: 390g F4 Flight Controller ( Diagram Picture) Item Name: Micro F4 FC AIO OSD BEC (D-Shot Version) MPU: 6000 CPU: STM32F405RGT6 Input Voltage: 2-6S Lipo Built-in Betaflight OSD to adjust PID BEC Output: 5V@3A Size: 30.5x30.5mm board, 3mm mounting holes (M3) Weight:7g Support Subs/PPM/DSMX receiver 50A BL_32 ESC Item Name: 50A 2-6S Blheli_32 RGB light ESC Input Voltage: 2-6S Lipo battery MOS Tube: TOP QUALITY MOSFET Constant Current: 50A Peak Current: 60A BEC Ouput: NO CPU: STM32F051 BLHELI_32 firmware Size: 26x15x6mm Weight: 7.4g Features: - Support Dshot 1200( in default),Oneshot42/125;Multishot;Dshot150/300 /600. - The color of RGB LED can be set by Blhelisuite - Powered by high performance STM32 MCU frequency up t0 48 MHZ - Composed of 3Oz gold plated PCB - Aluminum heat sink effectively slow down the temperature rise 2306 1800KV Brushless Motor Brand Name: Skystars Item Name: 2306 1800KV Brushless Motor 7 Inch Propeller Item Name: DP7056C 7 inch 3-Blade Propeller Color: Transparent White FPV Transmitter Output power: 25mW/200mW/500mW/800mW switchable button OR Channel changes and Pit mode setting through PWM With a microphone, you can switch the audio flexibly BAT: 7-26V,BEC 5V-1A 310mA----800mW Video system: NTSC/PAL Antenna: MMCX Frequency: 5.8GHz 5 bands 40 Channels Dimension: 36x36x4.85mm Mounting Hole: 30.5mmx30.5mm Weight: 4.2 g RunCam Swift 2 FPV Camera Brand Name: Runcam Model: Swift 2 Image Sensor 1/3" SONY Super HAD II CCD Horizontal Resolution 600TVL,4:3 Signal System PAL Integrated OSD YES Integrated MIC YES S/N Ration >60dB(AGC OFF) Electronic Shutter Speed PAL:1/50~100,000; NTSC:1/60~100,000 AutoGain Control(AGC) YES Back light compensation(BLC) YES Min.illumination 0.01Lux/1.2F WDR D-WDR DNR 2DNR Day/Night Color / Auto / B&W Power: DC 5 to 36V Net Weight: 14g Dimension: 28.5x26x26mm Pagoda2 FPV Antenna Size: 25mm x 25mm Gain: 1.6dbic Axial ratio: 1.0 (near perfect) Bandwidth: 5.5GHz-6.0GHz Radiation Efficiency: 95% VSWR:
