Simple Spectrum Analyzer D6 with Tracking Source T.G. V2.02 Simple Signal Source RF Frequency Domain Analysis Tool

File Click here to openFeature JTGP 1033 Simple Spectrum with Trace Generator Simple Signal Source Version V2 0Attribute RF Frequency Domain Analysis ToolInterface USBPower supply USBStandby current 100mASweep current le 350mASweep bandwidth 33mHz 4400mHzOpen Tracking Source Output Bandwidth 33 MHz 3000MHzSweep step 33 68 75 mHz 125 Hz 68 75 137 5 mHz 250 Hz 137 5 275 mHz 500 Hz 275 550 mHz 1 kHz 550 1100mHz 2kHz 1100 2200mHz 4kHz 2200 4400mHz 8kHzSweep frequency 800spot secondSweep Dynamic Logarithmic Ratio 50dBInput detection 10dBmComputer side software NWT4 11 09EditionComputer operating system WinXP win732 win764 Some of the installations of Win10 can be used and some cant The reason has not been found yet Its amazing Purpose RF circuit Two port network Frequency and amplitude characteristics analysis is the basis of RD debugging and maintenance of RF circuits The spectrometer is commonly known as a radiofrequency multimeter Applicable Radio enthusiasts studentsNote Because there are two high frequency oscillators tracking source oscillator and spectrum local oscillator on the circuit board of this product it is unavoidable that they interfere with each other when they work at the same time especially because the microwave band of the board size 99x75 is over 1500mhz has begun to appear Simple shielding to reduce this interference effect is very small do not Close the structure with a metal enclosure after all a prop on you
