Simonk Firmware 30A RC Brushless ESC with 2A BEC Support 2S 3S 4S T Plug/XT-60

Simonk Firmware 30A Brushless ESC for RC Fixed wing Drone Aircraft Airplane Plane AM1015E XT 60 FeaturesThe upper limit of the speed is up to 300000rpm in 2 poles 50000rpm in 12 poles and 42000rpm in 14 poles8KHz PWM control with speed control curveAutomatic throttle adaptation for more remote control devicesWith BEC the MCU separates the power supply and works more stableAutomatically select 2 4 LiPo the protection voltage is 6V 9V respectively Automatically select NiMH the protection voltage of each section is 0 8VSafe start throttle position is not allowed to startTemperature protection 110 degree surface temperature shutdownOut of control protection no signal stops after 1 second DescriptionType ESC Materials PCProduct weight 28g Package weight 35g Product size L x W x H 6 00 x 2 70 x 1 00 cmPackage size L x W x H 6 00 x 9 00 x 2 00 cmSpecificationExtreme use continuous current 30A instant 35A 40A for 10 secondsVoltage range 4 16VNumber of batteries 4 12 NiMH 2 4 LiPo 4 LiPo does not allow BEC output BEC output 2A continuous instantaneous 3A Package Included1 x Simonk Firmware 30A Brushless ESC for RC Fixed wing Drone Aircraft Airplane Plane AM1015E XT 60 3 x Banana Plug1 x Heat Shrink Tubing1 x Plug
