Sijiali L298N Dual H Bridge DC Stepper Control Board Motor Driver Module for Arduino

Specifications: The module has a Vcc input terminal and a 5V terminal which can either be an input or an output. The module can be powered either by inputting 7 to 35V on the Vcc terminal or by inputting 5V on the 5V terminal. There is a power button on the module that enables the Vcc input. When Vcc is enabled a red LED will light. If instead you use the 5V power input the switch is bypassed and the board will always be powered. The Vcc input feeds a built-in 5V regulator which is used by the L298N chip. If the input voltage is in the range of 7 – 12VDC there will be 5V available at the 5V terminal that can be used to power an for arduino or other 5V logic. The built-in 5V regulator can handle up to 400mA maximum. If Vcc is higher than 12VDC it is not recommended to use the built-in 5V to power other devices to avoid possible overheating of the 5V regulator. Using the Vcc input with a voltage between 7-12V gives the most flexibility when using this module and is the recommended mode to use. Type: Dual H-Bridge Motor Control Module Material: Plastic Peak Current: 2.5A Motor Voltage Range: 5-35V Total Power: 25W Features: Easy Installation Durable Good Replacement Note: Due to the light and screen setting difference the item’s color may be slightly different from the pictures. Package Includes: 1 x Dual H-Bridge Motor Control Module Please contact us to better resolve any issues before leaving neutral or negative feedback. If you have any questions please contact customer service.
