Signal Generator Signal Process Calibrator Portable For Electric Valve For Industry

Signal Generator Signal Process Calibrator Portable for Electric Valve for Industry Specification: Item Type: Signal Generator Product Model: RuoShui 71B Material: PlasticCapacitive Load: Greater than or equal to 0.01uF Display : 2-3 times/sec Overload Protection: 50mA / 30V Working Temperature And Humidity: 0-40 degrees Celsius and humidity below 85% (no condensation) Storage Temperature And Humidity: -20 degrees Celsius -60 degrees Celsius and humidity lower than 90% (no condensation) Ideal Working Environment: 23?5 degrees Celsius and humidity lower than 75% (no condensation) Temperature Coefficient: 0.1 x basic accuracy/ degrees Celsius (temperature 28 degrees Celsius ) Environmental Conditions For Use: Indoor/outdoor use (not waterproof) 0-2000m above sea level Out Of Range Display: OL Battery: 3 x AAA battery (Battery Not Included) Low Battery Warning: Support Automatic Power Off: Support Warm Up Time: 10Min Calibration: External calibration Calibration Period: 1 year Measurement Function Range Measuring Range Resolution Accuracy DC Voltage 100mV -10.0mV~110.0mV 100uV 0.2%+4 30V -5.00V~30.00V 10mV 0.2%+4 DC Current 20mA 0.00mA~22.00mA 0.01mA 0.2%+4 Thermocouple R 0 degrees Celsius ~1760 degrees Celsius 1 degrees Celsius 0.2%+4 S 0 degrees Celsius ~1760 degrees Celsius B 400 degrees Celsius ~1820 degrees Celsius K -200 degrees Celsius ~1370 degrees Celsius E -200 degrees Celsius ~1000 degrees Celsius J -200 degrees Celsius ~1200 degrees Celsius T -200 degrees Celsius ~400 degrees Celsius N -200 degrees Celsius ~1300 degrees Celsius Output Function Range Measuring Range Resolution Accuracy DC Voltage 100mV 0.0mV~110.0mV 100uV 0.2%+4 10V 0.00V~11.00V 10mV 0.2%+4 DC Current 20mA 0.00mA~22.00mA 0.01mA 0.2%+4 Analog Transmitter Simulation -20mA 0.00mA~-22.00mA 0.01mA 0.2%+4 Loop Power Loop 24V ?10% Thermocouple R 0 degrees Celsius ~1760 degrees Celsius 1 degrees Celsius 0.2%+4 S 0 degrees Celsius ~1760 degrees Celsius B 400 degrees Celsius ~1800 degrees Celsius K 0 degrees Celsius ~1350 degrees Celsius E 0 degrees Celsius ~700 degrees Celsius J 0 degrees Celsius ~950 degrees Celsius T 0 degrees Celsius ~400 degrees Celsius N 0 degrees Celsius ~1300 degrees Celsius Package List: 1 x Signal Generator (Battery Not Included) 2 x Test Line 2 x Connector 1 x Storage Bag 1 x Manual Note: Please read the instructions carefully before use and strictly abide by the rules and cautions cautions and warnings listed in the instructions
