Siglent SDS1204X-HD Oscilloscope 200MHz Bandwidth 4 Channels 2GSa/s Sampling Rate 12-bit High Resolution TFT-LCD Touch S

Specifications Model SDS1204X HDAnalog Channels 4 EXT Bandwidth 200 MHzVertical Resolution 12 bitSample Rate Max 2 GSa s one channel mode Memory Depth Max 100 Mpts ch one channel mode Waveform Capture Rate Max Normal mode 120 000 wfm s Sequencemode 500 000 wfm sTrigger Type Edge Slope Pulse width Window Runt Interval Dropout Pattern Video Qualified Nth edge Delay Setup Hold time SerialSerial Trigger and Decode Standard I²C SPI UART CAN LIN CAN FD Decode Only FlexRay Decode Only Measurement 50 parameters statistics histogram trend and track supportedMath 4 traces 2 Mpts FFT Filter x ÷ ∫dt d dt √ Identity Negation Absolute Sign ex 10x ln lg Interpolation MaxMinHold ERES Average Supports formula editorData Analysis Search Navigate History Mask Test Counter Bode plot and Power AnalysisDigital Channel Optional 16 channel maximum sample rate up to 1 GSa s record length up to 10 MptsUSB AWG Module Option One channel 25 MHz sample rate of 125 MHz wavelength of 16 kpts isolated outputI O USB 2 0 Host x3 USB 2 0 Device 10 M 100 M LAN External trigger Auxiliary output TRIG OUT PASS FAIL SBUS Siglent MSO Probe Standard Passive probe PP215 for each channelDisplay 10 1 TFT LCD with capacitive touch screen 1024 600 Features 1 High Resolution and Bandwidth Experience unprecedented clarity and precision with its 12 bit vertical resolution and 200 MHz bandwidth This oscilloscop
