Serial to WiFi Module TICC3200 SCM Wireless Transmission Industrial Grade Low Power Consumption C322

Feature: Processor TI CC3200 (Cortex-M4 core) Main frequency 80MHz Network parameters Network protocol IPv4, TCP, UDP, DHCP, DNS, HTTP, ARP. ICMP TCP Server maximum TCP number 3 Wi-Fi Standard 802.11 b/g/n Network mode AP / Station Number of AP mode access terminals 1 Frequency Range 2.412 GHz-2.484 GHz Transmit power 17.0 dBm @1 DSSS 17.25 dBm11 CCK 13.5 dBm @54 OFDM Receiving sensitivity -94.7 dBm @1 DSSS -87.0 dBm @11 DSSS -73.0 dBm @54 OFDM Transmission rate 802.11b: 11 Mbps 802.11g: 54 Mbps 802.11n: 54 Mbps Transmission distance Built-in maximum 180m (empty line of sight) External maximum 310m (empty line of sight, 3dbi antenna) Security Mechanism Security mechanism: WEP-A/WPA-PSK/WPA2-PSK Encryption type: WEP64/WEP128/TKIP/AES Antenna interface Built-in: onboard antenna Serial port Number of ports 2 Interface standard TTL serial port : 3.3V Data bit 5, 6, 7, 8 Stop bit 1, 2 Check Digit None, Even, Odd, Space, Mark Baud rate 300 bps - 3M bps Flow Control RTS / CTS Cache Receive 1K bytes Software Virtual serial port (USR-VCOM) Windows 2000 or higher (32 bit / 64 bit) Configuration method Built-in web page, serial AT command, network AT command Networking method UsrLink: "People" Customized Module Networking Mode SimpleLink: One-click networking capabilities provided by TI Unique features Registration package mechanism: with registration package when connecting or sending data (registration package can be set to MAC address or double-byte character) Synchronous baud rate function: Network command to change the serial port baud rate Secure encryption: support PC1 transparent data encryption and SSL Client function Webpage: Support for custom webpage features Transfer: Support Httpd Client and Websocket (web to serial) Very specific parameter Size 26.6x18.2x2.8 (mm) Operating temperature -40 - 85C (B38 Industrial Grade) -40 - 125C, 5 - 95% RH (no condensation) Operating Voltage DC 3.0 ~ 3.6 V Working current AP: 70mA @3.3V STA: 18mA @3.3V Bee value: 247mA @3.3V More Certification CE WEEE FCC ROHS Package includes: 1 x Module
