Sennheiser EK 100 G4 Wireless Camera Receiver, A: 516 - 558 MHz

Powerful camera receiver with a lightweight aluminum housing and for evolution wireless G4 100P Series systems. For documentary, Mobile Journalism and audio for video applications.Architect's SpecificationThe compact camera receiver with adaptive diversity technology is for use with a companion transmitter as part of a wireless RF monitoring system.
The receiver operates within eleven UHF frequency ranges, with a switching bandwidth of up to 42 MHz: 470 - 516 MHz, 516 - 558 MHz, 520 - 558 MHz, 566 - 608 MHz, 606 - 648 MHz, 626 - 668 MHz, 734 - 776 MHz, 780 - 822 MHz, 823 - 865 MHz, 806 - 810 MHz, 925 - 937.5 MHz; transmission frequencies are 1,680 per range and are tunable in 25 kHz steps. The receiver features 20 fixed frequency banks with up to 12 compatible frequency presets and 1 user bank with up to 12 user programmable frequencies.The receiver is menu-driven with a backlit LCD display showing the current frequency, frequency bank and channel number, metering of RF level, metering of AF level, lock status, battery status, muting function or line output level, and pilot tone evaluation. An auto-lock feature is provided to prevent settings from being accidentally altered.
The receiver parameters are programmable in the receiver menu.The receiver features a 3.5 mm audio output with a maximum output of +11 dBu (mono, unbalanced).Nominal/peak deviation is +/-24 kHz/ +/-48 kHz. Squelch threshold is adjustable to three levels: Low (5 dBmicroV), Middle (15 dBmicroV) and High (25 dBmicroV).The receiver incorporates the Sennheiser HDX compander system and a defeatable pilot tone squelch. Sensitivity is = 65 dB (typical). Intermodulation attenuation is >= 65 dB (typical); blocking is >= 70 dB. Signal-to-noise ratio at 1 mV and peak deviation is >= 110 dBA. Total harmonic distortion (THD) is The receiver is the Sennheiser EK 100 G4.
