Seiko Protection IC 10A Protection Board For 3S 11.1V 12V 12.6V 18650 Lipo Battery

Seiko Protection IC 10A Protection Board For 3S 11 1V 12V 12 6V 18650 Lipo Battery Description Item Name Lipo battery protection boardDimension 50 16 5 3mmWeight 2 4gCharging Voltage 12 6VMax Output Current Charging Current 10AMax Output Power Charging Power 126WUsage Suitable for 3 6V 3 7V lipo battery included 18650 26650 and other lithium polymer battery Electrical Parameters Min ValueTypical ValueMax ValueUnitSelf consumption Current121824AOver Charge Protection Voltage4 164 224 27VOver Charge Recovery Voltage4 14 164 2VOver Discharge Protection Voltage2 352 52 7VOver Discharge Recovery Voltage2 93 23 3VConduction Resistance202428mOvercurrent Protection Current182022AOvercurrent Delay Time51015msContinuous Working Current01010AContinuous Output Power0126126WAmbient Temperature 402585℃Features Excellent PCB design excellent workmanshipJapan Seiko lithium protection IC perfect protection functionThe United States MOS tube low resistance low lossAlloy resistance high temperature resistance and stabilityNote Strictly according to the diagram wiring 0V 4 2V 8 4V 12 6V do not deliberately short circuit After connecting the line need to be charging activated before the output Discharge test the voltage drop of the fastest group of batteries is the bad battery When three groups of batteries are connected in series please ensure that the voltage of each battery is the same If not please charge each battery separately and then use it in series Do not
