Seiko Protection IC 10A Protection Board For 3S 11.1V 12V 12.6V 18650 Lipo Battery

Seiko Protection IC 10A Protection Board For 3S 11.1V 12V 12.6V 18650 Lipo Battery Description: Item Name: Lipo battery protection board Dimension: 50*16.5*3mm Weight: 2.4g Charging Voltage: 12.6V Max. Output Current / Charging Current: 10A Max. Output Power / Charging Power: 126W Usage: Suitable for 3.6V,3.7V lipo battery (included 18650,26650 and other lithium polymer battery) Electrical Parameters: Min. Value Typical Value Max. Value Unit Self - consumption Current 12 18 24 A Over Charge Protection Voltage 4.16 4.22 4.27 V Over Charge Recovery Voltage 4.1 4.16 4.2 V Over Discharge Protection Voltage 2.35 2.5 2.7 V Over Discharge Recovery Voltage 2.9 3.2 3.3 V Conduction Resistance 20 24 28 m Overcurrent Protection Current 18 20 22 A Overcurrent Delay Time 5 10 15 ms Continuous Working Current 0 10 10 A Continuous Output Power 0 126 126 W Ambient Temperature -40 25 85 Features: Excellent PCB design, excellent workmanship Japan Seiko lithium protection IC,perfect protection function The United States MOS tube, low resistance, low loss Alloy resistance, high temperature resistance and stability Note: Strictly according to the diagram wiring 0V, 4.2V, 8.4V, 12.6V, do not deliberately short circuit. After connecting the line need to be charging activated before the output. Discharge test, the voltage drop of the fastest group of batteries is the bad battery. When three groups of batteries are connected in series, please ensure that the voltage of each battery is the same. If not, please charge each battery separately and then use it in series. Do not mix the good battery and the bad battery. 3 battery capacity / internal resistance of the closer the better. Package Included: 1x Protection Board
