Seeeduino Motor Shield V2.0 L298 Motor Driver for Mega UNO

Description The Motor Shield is a driver module for motors that allows you to use ARDUIN0 to control the working speed and direction of the motor Based on the Dual Full Bridge Drive Chip L298 it is able to drive two DC motors or a step motor The Motor Shield can either be powered directly by ARDUIN0 or by an external 5V 15V power supply via the DC jack This module can be used for the development of microrobots and intelligent vehicles etc The defined pins are D8 D13 on the ARDUIN0 Seeeduino board D8 D11 D12 D13 are 4 output pins for controlling the speed or the direction of the motor D9 D10 are enabled pins for two channels of the Motor Shield So mostly you would use these 6 pins for your motor control and you are able to drive at most two motors from one shield The Motor Shield is compatible with many boards for more details please click the picture below Features ARDUIN0 Seeeduino compatibleStandardized shape designLED enable indicatorLED rotation direction indicatorOvercurrent turn offBuilt around the dual full bridge drive chip L298Overcurrent protectionDimensions 100mm x65mm x30mmDocumentations Motor Shield V2 0 Eagle FileL298 DatasheetMotor Shield Library78M05 DatasheetMotor Shield 2 0 schematicswikiPackage includes 1 x Motor Shield
