Schneider Variable Speed Drive, ATV630C13N4, Black

range of product range of product Altivar Machine ATV320 product or component type Variable speed drive product specific application Complex machines variant Standard version mounting mode Wall mount communication port protocol Modbus serial range of product Altivar Process ATV600 product or component type Variable speed drive product specific application Process and utilities device short name ATV630 variant Standard version product destination Asynchronous motors Synchronous motors EMC filter Integrated with 150 m conforming to EN/IEC 61800-3 category C3 IP degree of protection IP00 conforming to IEC 61800-5-1 IP00 conforming to IEC 60529 IP21 (with kit VW3A9704) conforming to IEC 61800-5-1 IP21 (with kit VW3A9704) conforming to IEC 60529 type of cooling Forced convection supply frequency 50.60 Hz - 5.5 % [Us rated supply voltage 380. 480 V - 15.10 % motor power kW 132 kW (normal duty) 110 kW (heavy duty) motor power hp 200 hp normal duty 150 hp heavy duty line current 237 A at 380 V (normal duty) 213 A at 480 V (normal duty) 201 A at 380 V (heavy duty) 165 A at 480 V (heavy duty) prospective line Isc 50 kA apparent power 161.4 kVA at 480 V (normal duty) 121.8 kVA at 480 V (heavy duty) continuous output current 250 A at 2.5 kHz for normal duty 211 A at 2.5 kHz for heavy duty maximum transient current 275 A during 60 s (normal duty) 316.5 A during 60 s (heavy duty) asynchronous motor control profile Constant torque standard Optimized torque mode Variable torque standard synchronous motor control profile Permanent magnet motor Synchronous reluctance motor output frequency 0.00010.5 kHz speed drive output frequency 0.1599 Hz nominal switching frequency 2.5 kHz switching frequency 2.5.8 kHz with derating factor 2. 8 kHz adjustable safety function STO (safe torque off) SIL 3 discrete input logic 16 preset speeds communication port protocol Ethernet Modbus TCP Modbus serial option card Slot A: communication module Profibus DP V1 Slot A: communication module Profinet Slot A: communication module DeviceNet Slot A: communication module Modbus TCP/EtherNet/IP Slot A: communication module CAN open daisy chain RJ45 Slot A: communication module CAN open SUB-D 9 Slot A: communication module CAN open screw terminals Slot A/slot B: digital and analogue I/O extension module Slot A/slot B: output relay extension module Slot A: communication module Ethernet IP/Modbus TCP/MD-Link Communication module BACnet MS/TP Communication module Ethernet Power link Highlights Variable speed drive ATV630 - 130kW - 380.480V - IP00
