Schneider Electric VFD Altivar 630 Variable Speed Drive, ATV630U55N4, Black

0 Variable speed drive ATV630 - 5.5kW/7.5HP - 380...480V - IP21/UL type 1. range of product Altivar Process ATV600 product or component type Variable speed drive product specific application Process and utilities device short name ATV630 variant Standard version product destination Synchronous motors Asynchronous motors EMC filter Integrated with 50 m conforming to EN/IEC 61800-3 category C2 Integrated with 150 m conforming to EN/IEC 61800-3 category C3 IP degree of protection IP21 conforming to IEC 61800-5-1 IP21 conforming to IEC 60529 degree of protection UL type 1 conforming to UL 508C type of cooling Forced convection supply frequency 50...60 Hz - 5...5 % [Us rated supply voltage 380...480 V - 15...10 % motor power kW 5.5 kW (normal duty) 4 kW (heavy duty) motor power hp 7.5 hp normal duty 5 hp heavy duty line current 10.4 A at 380 V (normal duty) 9.1 A at 480 V (normal duty) 8 A at 380 V (heavy duty) 7.2 A at 480 V (heavy duty) prospective line Isc 50 kA apparent power 7.6 kVA at 480 V (normal duty) 6 kVA at 480 V (heavy duty) continuous output current 12.7 A at 4 kHz for normal duty 9.3 A at 4 kHz for heavy duty maximum transient current 14 A during 60 s (normal duty) 14 A during 60 s (heavy duty) asynchronous motor control profile Constant torque standard Variable torque standard Optimized torque mode synchronous motor control profile Permanent magnet motor Synchronous reluctance motor output frequency 0.00010.5 kHz speed drive output frequency 0.1599 Hz nominal switching frequency 4 kHz switching frequency 2...12 kHz adjustable 4...12 kHz with derating factor safety function STO (safe torque off) SIL 3 discrete input logic 16 preset speeds communication port protocol Modbus serial Modbus TCP Ethernet option card Slot Ais communication module Profibus DP V1 Slot Ais communication module Profinet Slot Ais communication module DeviceNet Slot Ais communication module Modbus TCP/EtherNet/IP Slot Ais communication module CANopen daisy chain RJ45 Slot Ais communication module CANopen SUB-D 9 Slot Ais communication module CANopen screw terminals Slot A/slot Bis digital and analog I/O extension module Slot A/slot Bis output relay extension module Slot Ais communication module Ethernet IP/Modbus TCP/MD-Link Communication module BACnet MS/TP Communication module Ethernet Powerlink
