Schneider Electric TeSys D Contactor Breaker, 3P (3 NO) AC-3 440V, 32A, 220 V AC Coil, LC1D32M7, Black

Range: Tests Product Name: Tests D Product Or Component Type: Contactor Device Short Name: Lc1D Contactor Application: Resistive Load Motor Control Utilisation Category: Ac-4Ac-1Ac-3 Poles Description: 3P Power Pole Contact Composition: 3 No Rated Operational Voltage: Power Circuit 690 V Ac 25.400 Hz Power Circuit 300 V Dc Rated Operational Current: 32 A 140 F (60 C)) 440 V Ac Ac-3 Power Circuit 50 A 140 F (60 C)) 440 V Ac Ac-1 Power Circuit Motor Power Kw 7.5 Kw 220.230 V Ac 50/60 Hz Ac-3) 15 Kw 380.400 V Ac 50/60 Hz Ac-3) 15 Kw 415.440 V Ac 50/60 Hz Ac-3) 18.5 Kw 500 V Ac 50/60 Hz Ac-3) 18.5 Kw 660.690 V Ac 50/60 Hz Ac-3) 7.5 Kw 400 V Ac 50/60 Hz Ac-4) Motor Power Hp (Ul / Csa) 2 Hp 115 V Ac 50/60 Hz 1 Phase 5 Hp 230/240 V Ac 50/60 Hz 1 Phase 7.5 Hp 200/208 V Ac 50/60 Hz 3 Phase 10 Hp 230/240 V Ac 50/60 Hz 3 Phase 20 Hp 460/480 V Ac 50/60 Hz 3 Phase 30 Hp 575/600 V Ac 50/60 Hz 3 Phase Control Circuit Type Ac 50/60 Hz Control Circuit Voltage 220 V Ac 50/60 Hz Auxiliary Contact Composition 1 No + 1 Nc Rated Impulse Withstand Voltage 6 Kv Iec 60947 Overvoltage Category: Iii Conventional Free Air Thermal Current 10 A 140 F (60 C) Signalling Circuit 50 A 140 F (60 C) Power Circuit Irms Rated Making Capacity 140 A Ac Signalling Circuit Iec 60947-5-1 250 A Dc Signalling Circuit Iec 60947-5-1 550 A 440 V Power Circuit Iec 60947 Rated Breaking Capacity 550 A 440 V Power Circuit Iec 60947 Rated Short-Time Withstand Current 260 A 104 F (40 C) - 10 S Power Circuit 430 A 104 F (40 C) - 1 S Power Circuit 60 A 104 F (40 C) - 10 Min Power Circuit 138 A 104 F (40 C) - 1 Min Power Circuit 100 A - 1 S Signalling Circuit 120 A - 500 Ms Signalling Circuit 140 A - 100 Ms Signalling Circuit Associated Fuse Rating 10 A Gg Signalling Circuit Iec 60947-5-1 63 A Gg 690 V Type 1 Power Circuit 63 A Gg 690 V Type 2 Power Circuit Average Impedance 2 Mohm - Ith 50 A 50 Hz Power Circuit. Highlights: New modern look & feel of all machines Easier to install and operate with multi-standard screws
