Schneider Electric Switch Disconnector iSW - 4P - 63 A - 415 V, A9S66463, White

Highlights: Schneider Electric 4P 63A 415V iSW Switch Disconnector is a Acti 9 iSW modular and reliable Switch disconnector It is a 4P, rated current is 63A and operating voltage is 415V AC, insulation voltage (Ui) 500V AC, red toggle Electrical endurance goes up to 15000 cycles and Mechanical endurance goes up to 20000 cycles The operating temperature is -25°C to +60°C The storage temperature is -40°C to +85°C The degree of protection is IP20 and IP40 in an enclosure It is DIN rail mountable The width in 9 mm pitches is 4 The dimensions are 36 mm width x 85 mm height x 73 mm depth This Switch disconnector is used for control and isolation This product is compliant with EN/IEC 60947-3, NZS 60947-3, AS 60947-3 and BS EN 60947-3 Opening and closing circuits under load Unambiguous Switching position indication by means of a green marking on the Switch knob of the device Additional add-on auxiliary modules (optional): Auxiliary Switch for status reporting (iOF) Tool-free assembly on the left side of the device Colour RAL 9003 The iSW Switch-disconnector complies with the following standards: IEC/EN 60947-3 Comes in white colour. Benefit from enhanced peace of mind with a complete modular system Consistency with the entire Acti9 range Easily open and close circuits under load
