SZT15--10V AC Current Transmitter Current Inductor AC 0-50A to DC 0-10V

6. Hysteresis is less than 1% and can be used under strong magnetic conditions. 7. The outer casing is made of self-extinguishing material ABS. 8. Suitable for AC current measurement and monitoring AC motor overload protection electronic switch of automatic control system and so on. Specification: Model: SZT15--10V Supply power: Not required Output type: 0-10V DC Input straight-through current: AC 0-10A/20A/50A Switch on minimum: 0.5±0.2A Maximum overload of straight-through current: 200% Accuracy: ±1% Power consumption: ≤1W Leakage current: ≤1mA Hysteresis: ≤1% Linearity: 10%-100% Straight-through wire diameter: 0.35-20mm Response time: ≤200ms Withstand voltage: 2000VAC 50/60Hz 1min Working environment: -20~60℃ 5-95%RH Dimensions: 61.5*90*26mm / 2.4*3.5*1.0inch Hole diameter: 20mm / 0.8inch Color: Black Material: plastic + metal Package Contents: 1 * AC Current Transmitter Only the above package content other products are not included. Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
