SWIT Electronics PB-M98S 98W Pocket V-Mount Battery with D-Tap and USB Output

The brick size V-mount batteries are always too big and heavy for field shootings, especially the handheld stabilizers, focus puller monitor, portable LED panel or small cameras. PB-M98S Pocket V-mount battery is designed for the above applications! It's only a DV battery size, with high capacity cells and still reaches 98Wh and without any compromise on the DC sockets!98Wh Fly FriendlyMax 100W/8A constant loadPB-M98S consists of 12pcs of high class 18650 battery cells, nominal voltage is 14.4V and reaches 98Wh / 6.6Ah high capacity. You can take this battery in carry-on luggage to board airplane. The Max constant load is 100W, 8A.Built-in D-tap and USBThe pocket size PB-M98S still has D-tap and USB sockets built-in. The D-tap socket share 100W/8A load DC output with the V-mount pins and support charging input by SWIT PC-U130B2 dual D-tap charger. The USB socket outputs 5V/2A for smart phone fast charging.5-LED Power IndicatorLow battery warningPB-M98S has 5-LEDs to indicator remaining power percentage. When remaining power is less than 10%, the last LED will flash automatically to remind changing battery.3A Fast ChargingPB-M98S can be charged by all standard V-mount chargers and D-tap chargers. The max charging current is 3A.SONY&RED CommunicationPB-M98S can communicate with both SONY and RED cameras and display digital power info on camera viewfinder.Wire-Free Internal TechPB-M98S has innovative "Wire-Free" internal technic. All the cells, D-tap, USB, power indicator devices are directly soldered onto PCB, no connecting wires, to reduce internal resistance effectively and make the circuit stable, safe and reliable.High quality Lithium cellsFor 20 years, SWIT has been leading brand of broadcast camera batteries. The first reason is the high quality Lithium cells we adopted. The high quality cells featured long life, durable, safety and most of all, the cells has very little difference to each other, which ensures the high performance of the whole battery pack. Moreover, the cells we're using, have a smooth discharging curve by voltage, so that you can judge the remaining running time accordingly. Also when in storage, the self-discharging rates are very little, that extends the battery life effectively.Multiple Safety Protection CircuitThe battery has an MCU to measure and record the real time data and will cut off power when over-voltage, under-voltage, over-current, high-temperature of low-temperature is detected.Cell balance adjustmentAfter the batteries are used for a period of time, the cells voltage might get difference and our specially designed circuit can optimize the imbalanced cells, to prolong the battery life.
