STM32F103VET6 ARM STM32 Minimum System Development Board Cortex-M3 Expansion Board Module

 Manual Click here to open Description Onboard the most basic circuits based on MCU such as crystal oscillator circuit power conversion circuit and USB interface etc The core board brings out the common I O port resources Added EEPROM peripherals to expand the memory circuit The SWD simulation debug download interface is introduced It uses the Mirco USB interface that is commonly used in smartphones today It is easy to use and can do USB communication and power supply With its own power supply voltage regulator chip the power inlet outlet is equipped with a tantalum capacitor which has an extraordinary effect in filtering and voltage regulation Equipped with high quality 2 54mm spacing of single rows of pins ensuring excellent conductivecontact Specification Model STM32F103VET6Core ARM 32 bit Cortex M3Work Frequency 72MHzFlash Memory 512K Byte Flash 64KByte RAMWorking Voltage 2 0 3 6VPower supply 3 3V regulator chip maximum output 1000mASize 62 48x44 7mm 2 46x1 76 inchColor Blue Package Included 1 x STM32F103VET6 ARM STM32 Minimum System Development Board
