SKYSTARS 2018 RXT-X219 LED version FPV Racing Drone PNP F4 OSD 25-600MW VTX (28% OFF Code: 28rc)

SKYSTARS 2018 RXT-X219 LED version FPV Racing Drone PNP F4 OSD 25-600MW VTX 40A Blheli_32 CCD Camera 28% off coupon: 28rc Specification: Brand name: SKYSTARS Item name: RXT-X219 LED Version Wheel base: 219mm Color: Black F4 8k flight controller: ICM20689 Six-Axis; OSD; Micro SD; 5V 3A BEC; Camera: Skystars 600TVL CCD micro Camera VTX: Skystars 25-600MW 7V-24V Version ESC: 40A Blheli_32 ESC 3-5S LED: 40xWS2812 with LED control;breathing light,alternating flashing,brightness control,extinguish etc. Motor: Skystarts ST2306 2500KV Propeller: Skystars 5049 Recommend battery: 3-4S 1500-1800mAH Product weight: 306g Product size: 190x195x45mm Package weight: 480g Packing size: 250x250x60mm Frame Kit: Wheelbase: 219mm Arm Plate Thickness: 6mm TOP&Bottom Plate Thickness: 2mm and 3mm Side Plate: 3D print TPU Material: 3k Carbon Fiber Weight: 75g Micro F4 Flight Control Board ( D-Shot Version): MPU: ICM20608 CPU: STM32F405RGT6, dual 8K. Input Voltage: 2-6S Lipo Built-in Betaflight OSD to adjust PID BEC Output: 5V@3A Size: 30.5x30.5mm board, 3mm mounting holes (M3) Weight: 7.3g Support Subs/PPM/DSMX receiver 40A 2-5S Blheli_32 4 in 1 ESC: Input Voltage: 2-5S Lipo battery Constant Current: 40A Peak Current: 50A BEC Ouput: [email protected] CPU: STM32F051 BLHELI_32 firmware Size: 36x36mm (main board) Installing Hole: 30.5x30.5mm, M3 Weight: 10g MOS Tube: TOP QUALITY MOSFET Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150/300/600/1200, forward and reverse Mini FPV Transmitter Output power: 25mW/100mW/600mW switchable Control mode:button OR Channel changes and Pitmode setting through PWM BAT: 7-26V,BEC 5V-1A 300mA----600mW Video system: NTSC/PAL Antenna: RPSMA Frequency: 5.8GHz 5 bands 48channels, with Raceband: 5362-5865 MHZ Weight: 8 g Dimension: 36*36*7.65 mm Mounting Hole: 30.5mmx30.5mm micro CCD Image Sensor: 1/3" SONY Super HAD II CCD Horizontal Resolution: 600TVL Lens: 2.1mm Lens FOV: 150 degree(2.1mm) Signal System: PAL / NTSC S/N Ratio: >60dB(AGC OFF) Electronic Shutter Speed: PAL:1/50-100,000; NTSC:1/60-100,000 AutoGain Control(AGC): YES Back light compensation(BLC): YES Min.illumination: 0.01Lux/1.2F WDR: D-WDR DNR: 2DNR Day/Night: Color / Auto / B&W Power: DC 5 to 36V Net weight: 5.6g Dimensions: 19mm * 19mm * 19mm Note: The PNP (Plug and Play) version comes without battery, charger, receiver or remote control. Package included: 1 x SKYSTARS 2018 RXT-X219 LED version FPV Racing Drone 1 x Frsky / Flysky receiver
