SHZICMY MPPT Wind Solar Hybrid Booster Charge Controller 800W+600W 12V/24V Auto Apply

Product function description: The controller is designed specifically for hybrid wind solar street light system which can make the wind solar hybrid street light system of various resources to achieve the best configuration of course the controller with some simple Settings can also be used in household system. Intelligent design succinct structure powerfulcontroll stable performance safety and reliability of the products.Choose MPPT Wind turbine charging ways charging more efficiency than ordinary PWM way more superior. The boost charge function solve the low charging efficiency problem of low wind speed . Professional digital intelligent control. 1.Wind generator MPPT boost charging function. 2.PWM dump load of wind external dump-load resistance intelligent disconnection of Solar charging. 3. Dual power supply function: Battery + solar power supply. 4. LCD displays parameters such as voltage and current of wind solar and load . 5.Two DC output with 4 output modes. 6.High performance and stable chip control. 7. The inner circuit board of the controller is sprayed to prevent dust moisture and static electricity. 8. 12V/24VAutomatic identification system voltage. Features: Condition:New Color:Green Model:1400W80 Rated voltage:12V/24V Automatic identification system voltage PV input power:600W Wind turbine power:800W Charging:58.3A/116.6A Even charge protection:14.4V±1%(12V) / 28.8V±1%(24V) Floating charge:13.8V±1%(12V) / 27.6V±1%(24V) Even charge recover:13.2V±1%(12V) / 26.4V±1%(24V) Temperature Compensation:-24mV/℃ -48mV/℃ Over Discharge-Shut off (DC):10.8V±1%(12V) / 21.8V±1%(24V) Over Discharge-Resume(DC):12.3V±1%(12V) / 24.6V±1%(24V) Over Voltage-Shut off (DC):16V±1%(12V) / 32V±1%(24V) Over Voltage-Resume(DC) :15V±1%(12V) / 30V±1%(24V) No-load Current≤0.1A Voltage drop(DC)≤0.5V Display:LCD Working Temperature:-25~+55℃ Environment humidity:0~90% No condensation Control modeWind turbine MPPT charge function PWM uninstall function PWM over-current limiting Show parametersvoltage charge current battery volumetric Protected typeLightning protection solar cells anti-anti-charge protection battery open-circuit protection battery reversal protection over speed and over-voltage soft automatic brake protection overload protection Heat emanation wayRadiator Status indication: Charge: (1) The light is always on and it is charging (2) Extinguished state non-charging state Out: (1) The light is always on and the load end is output normally (2) Extinguished state battery overvoltage (3) Flashing state battery undervoltage NOTE: Installation Manual Is NOT Included Professional Installation Is Highly Recommended Package includes: · 1 Set （As picture）
