SHZICMY 4 Axis 6090 CNC Router 3D Engrave rEngraving Machine Mill & Handwheel 2200 W USB

SHZICMY 4 Axis 6090 CNC Router 3D Engrave rEngraving Machine Mill & Handwheel 2200 W USB
sku: 2429274212
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$2,499.00
Shipping from: United States
   Description
4 Axis 6090 CNC Router 3D Engrave rEngraving Machine Mill & Handwheel 2200 W USB 3d 6090 Router 4 Axis+2.2kw Spindle Motor +Vfd +Usb Port Metal Wood Engraver with Tool Sensor Description Variable-frequency Drive(Vfd):Ac110v 2200w 0-400hz(Built-in Control Box ) (Tips:1 the Spindle Motor Must Connect with the Vfd.2 It Cannot Directly Connect with the Supply Voltage (Ac110v/220v).3 Please Don’t Change the Data Setting of the Vfd If You Are Not Professional Technicians or It Might Damage the Spindle Motor.) Drive of Stepping Motor 0-3.5a Adjustable Four-axis Drive(Tb6560ahqchip 24v Power Supply 2 4 8 16subdivision Settings Factory Setting:8subdivided) Repositioning Precision:≤0.05mm Speed:0-24000r/M Cooling Method:water Cooling Matching Heat Dissipation Water Pump Spindle Precision:radial Runout≤0.03mm Carving Command:g Code/Tab File/Nc/Tab /Ncc/File Protection:emergency Stop Button Communication Interface:through Usb Port Connect with Computer Support System:windows Xp / Win7 with 32bite Input Volts: Ac110v Gross Weight of Machine :About 145kg/320lb Update Function: with Limit Switch Application Industry: Woodworking Industry: Sculpture Round Carving Wooden Handicraft Processing Advertising Signs: Logo Making Cutting Acrylic Plastic Molding Suit for Making a Variety of Materials Advertising Decorative Products Other Industries: the Engraver Could Do Shadow-carved Sculpture Which Widely Used in the Gift Industry; Can Be Used in Aluminum Cutting Industry Such As Aluminum Aluminum-plastic Plate Aluminum Honeycomb Panels Aluminum 3d Engraving Process Artificial Plate Cutting Led and Neon Letter Making Plastic Light Box Model; Also Can Engrave on Acrylic Copper Pvc Board Artificial Stone Mdf Board and Other Metal Sheet. How to Use: 1.Assembling and Locating the 3d Machine on Steady Desk Well. 2.Make Sure That Your Computer Has a Usb Port Output. 3. Place the Control Box in a Ventilated Dry Place Where There Is No Dust No Moisture 4.Connecting the Control Box with the 3d Machine and You Computer and Make Sure the Plug Will Not Come off. 5.Correctly Connect the Machine with the Controller. Don t Suspended the Cable Which Connect the Spindle Motor with Axis(X Y Z a).Otherwise It Will Damage the Driver of the Controller. 6.Correctly Instal the Spindle Motor and the Heat Pump. the Heat Pump Should Be Covered Completely in the Water Then Turned on the Electric Current to Check Whether the Water-cooling System Working Well. 7. Before Turn on the Machine Please Check All the Cable and Water- Cooling System to Make Sure They Are Working Fine. 8.You Can Enjoy Making You Dream with Using Our 3d Machine Now. Package List: 1x Main Unit (Frame) 1x Main Unit (Working Base) 2x Fece Baffle 1x Control Box 1x a Axis 1x Sinal Cable for a Axis 1x Pump 1x Usb Cable 2x Cutter 2*6mm 2x Cutter 3*6mm 10x 4*7mm Round Head 6x 4*10mm Black Inner Six Angle Screw with Nut 8x 5*20mm Black Inner Six Angle Screw 4x 5*8mm Flat Philip s Head Screw with Nut and Gasket 8x 6*24mm Balck Flat Inner Six Angle Screw 12x Aluminium Fastener 1x 13-15# Wrench 1x 14-17# Wrench 2x Six Angle Wrench(3mm) 2x Six Angle Wrench(4mm) 1x Teflon Tape 2x Fuse (5a) 1x Power Cable 1x Manual 1x Tools Setting Auto-check Instrument for 3d
